Design and Optimization of FCEV Subframe by Integrated Applications of Hypermesh, UG and ADAMS Multi-Platform

Abstract:

The UG model and finite element model of FCEV subframe are established, and original subframe is simulated in all kinds of ADAMS environment, which result in the force of the conditions obtained. Then the virtual model is build, stiffness and strength analysis are conducted, and a new type of subframe structure is designed based on the analysis results. Magnesium alloy and aluminum alloy are used in optimization of this new structure for the optimal size. Through the comparative analysis on strength, stiffness, mode shape and quality of the new subframe and the original one, it was verified that the new subframe design is reasonable and feasible.

• Periodical: Advanced Materials Research (Volumes 328-330)
• Pages: 213-219
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.328-330.213
• Online since: September 2011
• Authors: Jun Liao
• Keywords: FCEV Subframe, Finite Element, Size Optimization, Structural Optimization

References

[1] Yu Zhisheng: Automobile theory (Machinery Industry Press, Beijing. 2009. 1).

[2] Liu WeiXin: Automobile design: Tsinghua University Press, Beijing. 2008. 10).

[3] Wu ChengJun, Wang Hongyan: Safety analysis of fuel cell car body structure based on virtual crash test Journal of Safety and Environment, 2006. 06.

[4] Liao Jun, Liu Jingzhong, HU Wangyue: Topology-optimization of the Fuel cell car's Vice-frame Structure Bulletin of Science and Technology , 2010 04.

[5] Liu Jun, Du Liping, Wang Fengliang, Hu Wangyue: Structural optimization of the electric car's frame based on OptiStruct Mechanical & Electrical Engineering Magazine , 2008 05.

[6] Liao Jun: Development of Lightweight Vehicle Technology Machinery 2009 01.
