Comparative Study on Vibratory Stress Relief (VSR) and Thermal Stress Relief (TSR) of Cylinder Wallboard

Abstract:

Dimensional stability of carding machine has a greater impact on the performance of the Cylinder wallboard. Compared with the thermal stress relief (TSR), the vibratory stress relief (VSR) is a new technology which may eliminate the residual stress in metal components with high efficiency, energy saving, environmental protection and low cost. We have 8 pieces of cylinder wallboard castings with every 4 pieces as a group. It takes 20 minutes to do VSR in one of the groups and 20 hours for TSR in another group. Three identical size accuracy indexes are measured, respectively at intervals of 1 month 2 months after aging treatment. The results show that: the dimensional stability of cylinder wallboard vibration by VSR is better than the one by TSR. Energy consumption and cost-saving is more than 90% without "three wastes" emissions.

• Periodical: Advanced Materials Research (Volume 331)
• Pages: 460-464
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.331.460
• Online since: September 2011
• Authors: Xue Wu Dong, Xi Ping Zhao, Song Qing Yu, Xiao Wen Zhou, Dai Ren, Ya Fei Zhai
• Keywords: Carding Machine, Cylinder Wallboard, Modal Analysis, Thermal Stress Relief (TSR), Vibratory Stress Relief (VSR)

References

[1] Xuewu Dong, Xiaowen Zhou and so on. Study of plate casting VSR Process Parameters Design Method [J]. Zhongyuan Institute of Technology, 2006, 17(4):1-3.

[2] Dongjiang Wang, Xuewu Dong and so on. Study of the optimization of the Casting VSR Excitation Frequency Parameters [J]. Group Technology and Production Modernization, 2008, 25 (3):48-51.

[3] Zaiji Hu, Xuewu Dong. Discussion of VSR Process [J]. Casting Technology, 1995, (3):26-31.
