Preparation of Cu₂ZnSnS₄ Film by Printing Process for Low-Cost Solar Cell

Abstract:

Cu₂ZnSnS₄ (CZTS) film was prepared by screen printing process with the advantages of simple, high-effective and cost-effective. The annealing effects on the screen printed CZTS films were studied. It was found that the crystallinity of the CZTS can be effectively improved by the annealing process, whereas overlong annealing can also introduce defects to the CZTS. The bandgap value of the CZTS is about 1.4 eV. The short-circuit current density, open-circuit voltage, fill factor and conversion efficiency of the best solar cell with superstrate structure of Carbon/CZTS/In₂S₃/TiO₂/FTO glass (without using any vacuum conditions) are 6.20 mA/cm², 290 mV, 0.29 and 0.53%, respectively.

• Periodical: Advanced Materials Research (Volumes 335-336)
• Pages: 1406-1411
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.335-336.1406
• Online since: September 2011
• Authors: Qin Miao Chen, Xiao Ming Dou, Zhen Qing Li, Shu Yi Cheng, Song Lin Zhuang
• Keywords: Cu₂ZnSnS₄, Low-Cost Non-Vacuum, Screen Printing, Solar Cell

References

[1] H. Katagiri, K. Jimbo, S. Yamada, T. Kamimura, W.S. Maw, T. Fukano, T.Ito and T. Motohiro: Appl. Phys. Express Vol. 1 (2008), p.041201

DOI: 10.1143/apex.1.041201

[2] H. Katagiri, K. Saitoh, T. Washio, H. Shinohara, T. Kurumadani and S. Miyajima: Sol. Energy Mater. Sol. Cells Vol. 65 (2001), p.141

DOI: 10.1016/s0927-0248(00)00088-x

[3] H. Katagiri: Thin Solid Films Vol. 480-481 (2005), p.426

[4] Z. Zhou, Y. Wang, D. Xu and Y. Zhang: Sol. Energy Mater. Sol. Cells Vol. 94 (2010), p. (2042)

[5] T.K. Todorov, K.B. Reuter and D.B. Mitzi: Adv. Mater. Vol. 22 (2010), p.156

[6] K. Tanaka, M. Oonuki, N. Moritake and H. Uchiki: Sol. Energy Mater. Sol. Cells Vol. 93 (2009), p.583

[7] N. Kamoun, H. Bouzouita and B. Rezig: Thin Solid Films Vol. 515 (2007), p.5949

DOI: 10.1016/j.tsf.2006.12.144

[8] C.P. Chan, H. Lam and C. Surya: Sol. Energy Mater. Sol. Cells Vol. 94 (2010), p.207

[9] L. Kavan and M. Gratzel: Electrochim. Acta Vol. 40(5) (1995), p.643

[10] T.T. John, S. Bini, Y. Kashiwaba, T. Abe, Y. Yasuhiro, C.S. Kartha and K.P. Vijayakumar: Semicond. Sci. Technol. Vol. 18 (2003), p.491

DOI: 10.1088/0268-1242/18/6/317

[11] A. Redinger and S. Siebentritt: Appl. Phys. Lett. Vol. 97 (2010), p.092111

[12] A. Redinger, D.M. Berg, P.J. Dale and S. Siebentritt: J. Am. Chem. Soc. Vol. 133 (2011), p.3320

[13] K. Ito and T. Nakazawa: Jpn. J. Appl. Phys. Vol. 27 (1988), p. (2094)

[14] Q. Guo, G.M. Ford, W.C. Yang, B.C. Walker, E.A. Stach, H.W. Hillhouse and R. Agrawal: J. Am. Chem. Soc. Vol. 132(49) (2010), p.17384

DOI: 10.1021/ja108427b

[15] T. Wada, Y. Matsuo, S. Nomura, A. Miyamura, Y. Chiba, A. Yamada and M. Konagai: Phys. Status Solidi (a) Vol. 203(11) (2006), p.2593

DOI: 10.1002/pssa.200669652
