The Research on Discrete Element of Blade Part In Powder Injection Molding

Abstract:

The 3D injection discrete element model of blade injection part is constructed. PFC3D is used to program for filling simulation and analysis. The simulation result shows that there is anisotropy and filling in injection direction first. There is difference between results by discrete element and by Moldflow software. There is large contact stress in reverse direction in sharp angle region and it is filled at last. The injection test result shows that the injection discrete element model is feasible.

• Periodical: Advanced Materials Research (Volume 338)
• Pages: 205-208
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.338.205
• Online since: September 2011
• Authors: Yu Liu, Yi Min Li, Qing Kun Xia, Hao He, Guang Yao Wang
• Keywords: Discrete Element, Granular Model, Powder Injection Molding

References

[1] Liu Yu: Powder Metallurgy Materials Science and Engineering, 2010, 15 (5):427-432

[2] Zhang Jianguang, Li Yimin, Liu Yu: Powder Metallurgy Materials Science and Engineering, 2009, 14 (2): 89-95

[3] T. Iwai, T. Aizawa, Kihara: Advances in powder metallurgy and particular materials, 1996, 5(2): 19-20

[4] Wang Anlin: Shanghai Jiao Tong University, 2005, 39 (5) :790-794

[5] Wei Qun:The numerical methods and the procedures of the basic principles of discrete element method. Beijing: Science Press, 1991:5-24

[6] C. Tamagnini: Journal of Engineering Mathematics, 2005, 52: 265-291
