Rigid-Plastic FEM Simulation of Orthogonal Cutting Process

Abstract:

This paper presents a rigid-plastic finite element method for orthogonal cutting process by adopting Lagrange method. The rigid-plastic FEM analysis model is established and the rigid-plastic FEM analysis toolkit was developed. Meanwhile, two relevant key problems are discussed systematically, including the rule of chip-workpiece separation and the criterion of tool-chip separation. At last, a simulation example of planing an aluminium alloy (ZL-301) workpiece was conducted. The effects of the cutting stroke, the tool rake angle and the friction coefficient on chip were observed. The numerical simulation results have a good agreement with their experimental ones. It is indicated that the presented FEM model and algorithm are efficient and correct.

• Periodical: Advanced Materials Research (Volume 338)
• Pages: 209-213
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.338.209
• Online since: September 2011
• Authors: Jiang Xin Zhu, Jian Xin Deng
• Keywords: Chip Formation, Numeric Simulation, Orthogonal Cutting, Rigid Plastic FEM

References

[1] Fnag Gang,Zeng Pan:Advanced in Mechanics Vol. 3 (2001), pp.394-404

[2] Movahhedy M,Gadala M S and Altintas Y: Journal of Material Processing Technology Vol. 103 (2000), pp.267-275

[3] M.Mohammadpour: Simulation Modelling Paractice and Theory Vol. 18 (2010), pp.378-389

[4] Mohammad Sima: International journal of Machine Tools&Manufacture Vol. 4 (2010), pp.1-18

[5] V.Schulze: CIRP Annals-Manufacturing Technology Vol. 59 (2010), pp.117-120

[6] Domenico Umbrello: Materials and Design Vol. 30 (2009), pp.160-165

[7] WenJun Liu, Wei Xia and ZhaoYao Zhou:Chinese Journal of Mechanical Engineering Vol. 3 (2004), pp.71-75 (In Chinese)

[8] MingQuan Tang : Thoery of Metal Cutting(Fujian Science and Technology Press, China 1984). (In Chinese)
