The Strength Analysis of Rotor Sleeve and PM for High-Speed Electrical Machine

Abstract:

For high-speed permanent magnet (PM) electrical machine, the PM material has very small tensile stress, and it can’t withstand the huge centrifugal force. So, a high-strength sleeve with interference fit is necessary to protect the PM. This paper mainly analyzes the strength of rotor sleeve and PM. It deduces the theoretical calculation method of the strength according to Lame equation, and it also analyzes the stress of sleeve and PM by ANSYS Workbench. The result show that the theoretical calculation value is closely to the ANSYS result, and it can meet the requirements of protecting the permanent magnet in high rotation speed.

• Periodical: Advanced Materials Research (Volume 338)
• Pages: 477-480
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.338.477
• Online since: September 2011
• Authors: Hong Chang Ding, Lin Jing Xiao
• Keywords: High-Speed, Interference Fit, Permanent Magnet Electrical Machine, Strength Analysis

References

[1] Arkkio A., Jokinen T, Lantto E. Induction and permanent-magnet synchronous machines for high-speed applications[C]//Proceedings of the 8th International Conference on Electrical Machines and Systems-ICEMS 2005, 2005: 871~876.

DOI: 10.1109/icems.2005.202668

[2] Bianchi, N, Bolognani, S, Luise F. Potentials and limits of high-speed PM motors[C]//IEEE Transactions on Industry Applications, 2004: 1570~1578.

DOI: 10.1109/tia.2004.836173

[3] Jiqiang WANG, Fengxiang WANG, Wenbo BAO: Chinese Proceedings of the CSEE, Vol. 25 (2005), p.140(In Chinese).

[4] Bingye XU, Xinsheng LIU. Application of elastic plasticity. (Chinese Tsinghua university press, China 1995)(In Chinese).

[5] Lanoue F, Vadean A, Sanschagrin B: Simulation Modelling Practice and Theory, Vol. 17 (2009), p.1587.

DOI: 10.1016/j.simpat.2009.06.017
