Temperature Field in Electric Control Unit of Diesel Engine and its Optimization Design

Abstract:

In order to satisfy the requirements of the high reliability of electric control unit (ECU) of the Diesel Engine, the thermal analysis of ECU was performed by using the software FLOTHERM based on the finite volume method. The temperature field of ECU was obtained under different operating conditions. The structural optimization of ECU was completed to solve the problem of local high temperature. As a result, the operational temperature of ECU is reduced under the allowable limit, and its reliability is improved. The physical experiment shows that the thermal analysis and structural optimization are valid. The local high temperature could be reduced effectively and the operational reliability is improved.

• Periodical: Advanced Materials Research (Volume 340)
• Pages: 76-80
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.340.76
• Online since: September 2011
• Authors: Zhen Jie Liu, Yu Long Lei, Yong Jun Li
• Keywords: Diesel Engine, ECU, Thermal Analysis

References

[1] Xu Q k, Zhu K Q, Chen Z Q. Reseach on responsibility of solenoid valve driver circuit for high pressure common rail diesel engine,. Chinese International Combuston Engine Engineering, Vol. 28(3), pp.15-19, Jun (2007).

[2] Li X B. Power electronic component and its application,. Beijing: China Machine Press, (2001).

[3] Wang F P, Yang P. Heat dispersion calculation of power switching divece,. Telecom power Technologies, Vol. 22(1), pp.31-33, Feb (2005).

[4] Wang J N, Wang W, Yan W J. Circuit simulation based on Altium Designer,. Inner Mongolia Science Technology&Economy, p.27, Apr (2008).

[5] Zhang Z O. Thermal analysis of the printing unit board module,. Mechatronics Conference, pp.310-315, Jan (2007).

[6] Li G Y, Liu Z J, Qin D T. Temperature field in transmission control unit of dual-clutch automatic gearbox and its optimization design,. Journal of Lanzhou University of Technology, Vol. 36 (4), pp.56-60, Aug (2010).

[7] Cheng X, Shi X H. Optimization Design of heatsinks Based on Flotherm,. Structural Mechanical Process and Microwave Electronics Conference, pp.236-239, Sep (2008).
