System Frequency Stabilization Using Doubly Fed Induction Generators Based Wind Energy Conversion Systems

Abstract:

The conventional decoupling controls of variable-speed doubly fed wind turbines provide minimal support to the regulation of system frequency. The characteristics of doubly fed induction generator (DFIG) wind turbines and conventional power plans are compared, and the contributions of DFIG to system inertial response and frequency regulation are investigated. The influence of auxiliary loop parameters on the inertial response is illustrated. We also introduce a novel algorithm to enhance the participation of DFIG in existing frequency regulation mechanisms. The proposed approach takes advantage of the fast responses associated with DFIGs. The control system consists of four functional modules, namely, frequency control, rotational speed delay recovery, speed protection, and coordination control with conventional generators. The simulation results show that the control strategy has a fast response speed to the transient frequency error, thereby proving that wind farms can participate in system frequency regulation to a certain extent.

• Periodical: Advanced Materials Research (Volumes 347-353)
• Pages: 1442-1453
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.347-353.1442
• Online since: October 2011
• Authors: Ying Cheng Xue, Neng Ling Tai
• Keywords: Double Fed Induction Generation (DFIG), Frequency Regulation, Inertial Response, Power Control, Wind Turbine Generators

References

[1] A. Causebrook, D. J. Atkinson, and A. G. Jack, Fault ride-through of large wind farms using series dynamic braking resistors (March 2007),IEEE Trans. Power Syst., vol. 22, no. 3, p.966–975, Aug. 2007.

DOI: 10.1109/tpwrs.2007.901658

[2] European Wind Energy Association (EWEA), Large Scale Integration of Wind Energy in the European Power Supply: Analysis, Issues and Recommendations, 2005. [Online]. Available: http://www.ewea.org/.

[3] Wind Turbines Connected to Grids With Voltages above 100 kV—Technical Regulation for the Properties and the Regulation of Wind Turbines, Elkraft System and Eltra Regulation, version TF 3.2.5, Dec (2004)

[4] National Grid Company plc: The Grid Code, Issue 3, Revision 17, September (2006)

[5] Grid Connection Regulations for High and Extra High voltage, E.ON Netz GmbH, 1 April (2006)

[6] J. Ekanayake and N. Jenkins. Comparison of the Response of Doubly Fed and Fixed-Speed Induction Generator Wind Turbines to Changes in Network Frequency. IEEE Trans. Energy Conversion, Vol. 19, No. 4,, pages 800–802, 2004.

DOI: 10.1109/tec.2004.827712

[7] J. Morrenetal. Wind turbines emulating inertia and supporting primary frequency control，IEEE Trans. Power System. ， vol. 21， no. 1，pp.433-434，Feb.2006.

DOI: 10.1109/tpwrs.2005.861956

[8] G. Ramtharan, J.B. Ekanayake and N. Jenkins, Frequency support from doubly fed induction generator wind turbines, IET Renew. Power Generation. 2007, 1, (1), p.3–9

DOI: 10.1049/iet-rpg:20060019

[9] R.G. Almeida and J. A. Peças Lopes, Participation of doubly fed induction wind generators in system frequency regulation. IEEE Trans on Power Systems, 2007, 22 (3):944-950.

DOI: 10.1109/tpwrs.2007.901096

[10] L.R. Changchien C.M. Hung, Y.C. Yin. Dynamic reserve allocation for system contingency by DFIG wind farms. IEEE Trans on Power Systems, 2008, 23(2): 729-73

DOI: 10.1109/tpwrs.2008.920071

[11] M. Akbari,Seyed M.madani; Participation of DFIG based wind turbines in improving short term frequency regulation, Electrical Engineering (ICEE), 2010 18th Iranian Conference on Digital Object Identifier: 2010 , Page(s): 874 - 879

DOI: 10.1109/iraniancee.2010.5506955

[12] M. Bhuiyan, D.Sundaram;Comparing and Evaluating Frequency Response characteristics of Conventional Power Plant with Wind Power Plant. http://webfiles.portal.chalmers.se/et/MSc/BhuiyanDinakarMSc.pdf

[13] P. Kundur, Power System Stability and Control. New York: McGraw-Hill, 1993.

[14] N.R. Ullah, Added Value for Network Operation. http://webfiles.portal.chalmers.se/et/PhD/UllahNayeemPhD.pdf

[15] N. R. Ullah, T. Thiringer, D. Karlsson,Temporary Primary Frequency Control Support by Variable Speed Wind Turbines –Potential and Applications, IEEE Trans.Power Systems, vol. 23, no. 2, pp.601-612,May 2008.

DOI: 10.1109/tpwrs.2008.920076

[16] G.C. Tarnowski, P.C. Kjar, P.E. Sorensen, J.O.stergaard, Variable Speed Wind Turbines Capability for Temporary Over-Production,Power & Energy Society General Meeting, 2009. PES '09. IEEE

DOI: 10.1109/pes.2009.5275387

[17] J. M. Mauricio, A. Marano, A. G. Mez-Exp Sito, Frequency regulation contribution through variable-speed wind energy conversion systems. IEEE Trans on Power Systems, 2009, 24(1): 173-179

DOI: 10.1109/tpwrs.2008.2009398

[18] O. Anaya-Lara， F. M. Hughes， N. Jenkins， and G. Strbac， Contribution of DFIG-based wind farms to power system short-term frequency regulation，IEE proceedings. Part C, Generation, Transmission, and Distribution . vol. 153,no. 2, p.164–170, 2006.

DOI: 10.1049/ip-gtd:20050264

[19] V.Chemmangot Nayar， W.Mochamad Ashari, W.L. Keerthipala,A grid-interactive photovoltaic uninterruptible power supply sys-tem using battery storage and a back up diesel generator, IEEE Transactions on Energy Conversion, Vol. 15, No. 3, pp.348-352, September 2000.

DOI: 10.1109/60.875502
