The Establishment of Unified Coordinate System in Microtarget-Automatic-Assembly System

Abstract:

There are three subsystems in Microtarget-Automatic-Assembly System which is used in Inertial Confinement Fusion(ICF). It is microscopic image measurement subsystem,confocal probe measurement subsystem and three-dimensional motion subsystem. It is necessary to establish a unified coordinate system in order to interact information in three subsystems and provide accurate and reliable position and attitude information for micro-operating system.Each coordinate system and its errors are analyzed in this paper.In the end,the way to establish the unified coordinate system is given. It is proved that this subsystem meets the requirements for precision.

• Periodical: Advanced Materials Research (Volumes 347-353)
• Pages: 1454-1457
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.347-353.1454
• Online since: October 2011
• Authors: Xing Hua Li, Hai Qiang Wang
• Keywords: Confocal-Probe Measurement, Coordinate System, ICF, Microscopic-Image

References

[1] Jie Zhang, Physics, 1999, 28(3): 142-152

[2] Suter, L, J, in:The 30th Intemational Conference on Plasma Science, 2003, ICOPS 2003: 376

[3] Wenrong Wu, Lizhen Huang, Min Luo. The tenth China academic Conference on nuclear target technology, 2009: 63-64

[4] Zurong Qiu, Ting Wang, Jinjiang Wang, Xinghua Li, Ying zhong. J.Vac Sci Techn01.B, 2009, 27(4): 1890～1896.

[5] Hongwei Gao, Chengdong Wu, Bin Li, Opto-Electronic Engineering, 2006, 33(7): 68-73

[6] Zurong Qiu, Ting Wang, Benxuan Chen. Chinese Journal of Sensors and Actuators ,2009, 22(5): 751-754

[7] D.W. Eggert, A. Lorusso, R.B. Fisher. Machine Vision and Applications, 1997, 9(5-6): 272-290.
