The Application of Improved HHT to Harmonic Analysis and Fault Detection of Power System

Abstract:

Hilbert-Huang transform (HHT) is a new time-frequency-domain analysis method, which is suitable for non-stationary and nonlinear signals. In this paper, endpoint continuation and ensemble empirical mode decomposition (EEMD) decomposition method are introduced to improve the HHT, which solve the endpoint winger and modal aliasing problem. The improved HHT (IHHT) is used for analyzing the harmonic signal and detecting the fault signal of power system. Simulation results show that IHHT is feasible and effective for harmonic analysis and fault detection.

• Periodical: Advanced Materials Research (Volumes 354-355)
• Pages: 1406-1411
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.354-355.1406
• Online since: October 2011
• Authors: Wen Hua Han, Hai Xia Ren, Xu Chen, Xiao Juan Tao
• Keywords: EEMD, Endpoint Continuation, Fault Detection, Harmonic Analysis, HHT

References

[1] Louie K.W., Wilson P., Mazur R., etal. Power System Harmonic Analysis in the Frequency Domain. Canadian Conference on Electrical and Computer Engineering, 2007: 1421-1424

DOI: 10.1109/ccece.2007.357

[2] Zhenghua Li. Hilbert-Huang Transform Based Application in Power System Fault Detection. International Workshop on Intelligent Systems and Applications, 2009: 1-4

DOI: 10.1109/iwisa.2009.5072894

[3] Norden E. Huang, Zheng Shen, Steven R. Long, et al. The empirical mode decomposition and the Hilbert spectrum for nonlinear and non-stationary time series analysis [C]. Proc. R. Soc, Lond, 1998, A454: 903-995.

DOI: 10.1098/rspa.1998.0193

[4] Ting Wang, Gang Liu. An improved method to solve the end effect of EMD and its application on vibration signal. 2009 International Conference on Mechatronics and Automation. 2009: 3977-3981

DOI: 10.1109/icma.2009.5244866

[5] Ding Zhiqin, Ren Wentao, Wang Kai. The application of mirror closed endpoint continuation upon restraining endpoint effect. 2011 International Conference on Electric Information and Control Engineering (ICEICE), 2011: 4573-4575

DOI: 10.1109/iceice.2011.5777446

[6] Jinshan Lin, Qian Chen. Application of the EEMD method to multiple faults diagnosis of gearbox. 2010 2nd International Conference on Advanced Computer Control (ICACC), 2010, 2: 395-399

DOI: 10.1109/icacc.2010.5486649

[7] Ruoyu Wang, Yuefeng Zhang, Jinghong Guo. Power harmonic analysis based on Orthogonal Trigonometric Functions Family. 2010 China International Conference on Electricity Distribution (CICED), 2010: 1-7

[8] Yu-hua Zhang. Harmonic Analysis of Power System Based on Matlab [J]. Journal of Electric Power, 2009, 24(3): 229-231(in Chinese)
