High Power Inverter Circuit from GTO to IGCT and its Application on AC Driving Locomotive

Abstract:

IGCT is a kind of new type power electronic device which developed from GTO and IGBT . In this paper, Author based on analysis of the internal structure of GTO, shows how GTO development IGCT through technical methods.Through simulation of its off and on performance, the work curve and comparing results of the two devices are given. Then on two components of the inverter circuits are analyzed and compared. Thinking in large power AC drive locomotive, IGCT inverter is greatly simplifier than GTO inverter circuit, and superior performance,it will become the main converter for AC driving locomotive.

• Periodical: Advanced Materials Research (Volumes 354-355)
• Pages: 1394-1399
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.354-355.1394
• Online since: October 2011
• Authors: Su Rong Qu, Zhong Yang Zhang
• Keywords: AC Drive Traction Locomotive, GTO, High Power, IGCT, Inverter Circuit

References

[1] Shike Yu, the new power electronics device IGCT and its application [J], in the world of electronic components, 2006 (3) : 1-3"In Chinese"

[2] Shiming Guo, power electronic technology [M], chengdu: southwest jiaotong university press, 2008"In Chinese"

[3] Yongdian Peng, the commutation mechanism of IGCT[J], Electric drive for locomotives, 2004 (1) : 24-27"In Chinese"

[4] Yong Zhou, ZhongBin Lv, IGCT and inverter circuits of Pspice simulation [J], Electrical Drive Automation, 2006 (3) : 22-24"In Chinese"

[5] Qing Li ,Ping Liu, IGBT power E. Such inverter, power electronic technology [J], 2003 (6) : 7-9. "In Chinese"

[6] Xishan Liu, Ke Liu, Changxing Li, a new device the large volume of IGCT PWM variable frequency speed regulation system [J], Electrical Drive Automation ,2005 (4) : 36-38"In Chinese"

[7] Wenzhao Yang, Duochang He, KZ4A AC drive electric locomotive of the converter [J], Electric drive for locomotives, 2005 (6):15-18"In Chinese"
