Research on a Current Direct Control Method

Abstract:

A current direct control is proposed in the paper. The topology structure of a hybrid filtering equipment is presented. The traditional current detecting and controlling method for the structure is discussed. The relationship between the grid current and harmonic suppressing current is educed, which proves that the step of harmonic detection be left out in theory. A current direct control based on the grid current error is proposed, which is simple. It is not necessary to detect harmonic and reactive current. So influence factors on the real time and precision of the filter are reduced. The simulating model of the hybrid filtering equipment is constructed and the new current direct control is applied in the model. The simulating results show that the good performance of harmonic suppression and reactive compensation is obtained with the current direct control.

• Periodical: Advanced Materials Research (Volumes 354-355)
• Pages: 881-885
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.354-355.881
• Online since: October 2011
• Authors: Yan Li, Gang Li
• Keywords: Current Direct Control, Harmonic Suppression, Hybrid Filtering Equipment, Reactive Compensation

References

[1] Akagi H，Kanazawa Y，Nabae A.Instantaneous Reactive Power Compensator Comprising Switching Devices Without Energy Storage Components[J].IEEE Trans. on IA，1984，20 (3): 625- 630.

DOI: 10.1109/tia.1984.4504460

[2] Chen Qiuming．A simple on-line methode of detecting reactive current and harmonic current[J]. Proceedings of the CSEE，2006，26(14)：71-74(in Chinese)．

[3] Chen Donghua，Xie Shaojun，Zhou Bo．An improved synchronous reference frame method for harmonics and reactive current detection of active power filters[J]．Proceedings of the CSEE，2005，25(20)：62-67(in Chinese)

[4] Deng Wenlang，Yang Xinrong，Zhu Jianlin，Study of closed loop control based on double synchronous rotating frame for two-stage matrix converter under unbalanced load[J]．Proceedings of the CSEE，2006，26(19)：70-75(in Chinese)．

DOI: 10.1109/ccdc.2008.4598001

[5] Gao Dawei，Sun Xiaorui．A detecting approach of three-phase distortion currents based on adaptive linear neural network and its being realized[J]． Proceedings of the CSEE，2001，21(3)：49-52(in Chinese)．

[6] Zeng Zhezhao，Wen Hui，Wang Yaonan．An approach with high accuracy for intelligent analysis of power system harmonics [J]．Proceedings of the CSEE，2006，26(10)：23-27(in Chinese)．

[7] TU Chun-ming, SHUAI Zhi-kang, LI Hui. Principle and Compensation Characteristics of Resonant Impedance Type Hybrid Active Power Filter[J]. Proceedings of the CSEE，2009，28(25)：146-152(in Chinese)
