Theoretical and Numerical Analysis on the Seismic Response of Underground Structures in Existence of Isolators

Abstract:

In this paper, an analytical method of the beam with springs and dampers fixed at the ends was proposed based on equivalent single degree of freedom (SDOF) system and secondary Lagrange’s dynamic equations, in order to develop a new effective method to enhance the aseismic capability of underground structures. The dynamic response of elastically supported and damply supported beams subjected to both seismic loading and static axial loading was analyzed by the proposed analytical procedure. The theoretical results were validated by the numerical simulation. In order to further investigate the effects of springs and dampers fixed at the ends of the columns in nonlinear response situation, the 3D nonlinear seismic responses of the Dakai metro station structure with and without the isolators were analyzed by ABAQUS respectively. It is demonstrated that: (1) the proposed analytical procedure can predict the dynamic response of beams with elastic and damper supports subjected to both seismic loading and axial loading. (2) Setting isolators at the supports of the column could enhance the aseismic capability of the structure effectively. (3) The axial static loading induced by the gravity of the soil and structure provide the constraint on the column, and therefore could not be neglected in the structural dynamic analysis.

• Periodical: Advanced Materials Research (Volumes 368-373)
• Pages: 710-714
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.368-373.710
• Online since: October 2011
• Authors: Jin Chun Liu, Yi Huan
• Keywords: 3D Nonlinear Dynamic Response, Isolator, Seismic Loading, Theoretical Analysis, Underground Structure

References

[1] Qin Fang, Maolin Du: Mechanics in Engineering Vol. 28 (2006), pp.53-56, In Chinese

[2] Qin Fang, Li Chen, Maolin Du: Engineering Mechanics Vol. 25 (2008), pp.194-199, In Chinese

[3] Yi Huan, Qin Fang, Li Chen, Yadong Zhang: Transactions of Tianjin University Vol. 14 (2008), pp.414-421

[4] ABAQUS Inc.: Analysis User's Manual of ABAQUS 6.6 Volume III: Materials (ABAQUS Inc., American 2007)

[5] Jianfeng Zhao: Analysis of Nonlinear Seismic Response of Bridge Accounting for SSI and Multiple Excitation (Beijing University of Technology, P R China 2007), In Chinese

[6] Shuguang Wang: The Research on the Isolation of the Tall Building Structure and the Industrialization Exploitation of the Device (Nanjing University of Technology, P R China 2008), In Chinese
