Performance Research of VW-1-011 Type Ball and Cage Universal Joint

Abstract:

VW-1-011 type ball and cage universal joint is applied widely in automobile, which performance directly affects the safety of car driving. It is important significance to research the performance of cage-type universal joint as its force complex. The diversity important position of ball and cage is analyzed by FEA ALGOR software in paper, and the distribution of stress or strain is obtained, which the results provide a theoretical basis and reference for the designer of Cage-type universal joint.

• Periodical: Advanced Materials Research (Volume 381)
• Pages: 114-117
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.381.114
• Online since: November 2011
• Authors: Qing Yu
• Keywords: ALGOR, Cage Universal Joint, Finite Element

References

[1] Zhang hanxu, liu weisheng, wang wei: Bearing, Vol. 2 (2002), pp.9-10.

[2] Si baoshu: Bearing Vol. 2 (2001), pp.8-10.

[3] Liu changli: ALGOR finite element analysis software tutorial (Posts & Telecom Press, Beijing 2005).

[4] Schmelz F. Graf vun H C Scherr-Thoss and Aucktor E: Universal joints and driveshafts (Beijing Institute of Technology Press, Beijing 1998).

DOI: 10.1007/978-3-662-02746-2
