Study and Application of the Variable Torque Slipping Clutch with Skewed Rollers

Abstract:

The Variable Torque Slipping Clutch with Skewed Rollers is a new type of power transmission component, which combines both clutch and bearing functions, and has broad application prospects in industrial products. This paper describes its configuration, operating principle and characteristics. The present situation of its study and application at home and abroad and key issues needed to be further studied are also introduced.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 1671-1676
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.1671
• Online since: November 2011
• Authors: Ming Feng, Wei Xing, Jun Wei Lian, Guang Rong Yan
• Keywords: Bearing, Clutch, Friction, Hyperboloid, Torque

References

[1] Z. Rigbi, An Adjustable-torque Slipping Clutch, Tribology International, Vol. 30, pp.455-457, (1997).

DOI: 10.1016/s0301-679x(96)00072-2

[2] M. Feng, K. Ono., and M. Kenji., Fundamental Characteristics of A New Variable Torque Clutch with Skewed Rollers, ASME Journal of Mechanical Design, Vol. 123, pp.436-446, (2001).

DOI: 10.1115/1.1372191

[3] H. B. Chen, Theoretical Analysis of Roll-shaped Curve and Experimental Results of Pipe (Stick) Material Straightening Machine, Acta Mathematicae Applicatae Sinica (in Chinese), No. 2, pp.17-32, (1976).

[4] K. Liu, S. Y. Niu, Z. Liu, Z. T. Ruan, H. Q. Wei, Research on the Curved Surface of Bearing Clutch, " Journal of Xi, an University of Technology (in Chinese), Vol. 10, No. 1, pp.6-12, (1998).

[5] K. Liu, S. Y. Niu, Z. Liu, Z. T. Ruan, Analysis of the Motion and Forces of Roller Bearing Clutch, Mechanical Science and Technology (in Chinese), Vol. 17, No. 4, pp.258-261, (1998).

[6] K, Liu, S. Y. Niu, Z. Liu, Z. T. Ruan, Analysis of Rolling Friction Power Loss of Roller Bearing Clutch, Mechanical Science and Technology (in Chinese), Vol. 17, No. 4, pp.603-605, (1998).

[7] Y. F. Yin, Z. Y. Chang, Z. Liu, Dynamic Properties Analysis for Roller Bearing Clutch, Journal of Taiyuan University of Science and Technology (in Chinese), Vol. 27, No. 4, pp.281-284, (2006).

[8] Y. F. Yin, Z. Y. Chang, Z. Liu, Film Thickness Calculation for Roller Bearing Clutch, Lubrication Engineering (in Chinese), No. 10 (182), pp.148-150, (2006).

[9] Q. X. Duan, Y. F. Yin, Z. Liu, The Stress Analysis of Roller Bearing Clutch Based on ANSYS, Modern Manufacturing Engineering (in Chinese), No. 1, pp.84-86, (2008).

[10] M. Feng, K. Ono, and M. Kenji, Studies on Contact Geometry and Limiting Resistant Torque Characteristics of the Variable Torque Slipping Clutch with Skewed Rollers, JSME International Journal Series C, Vol. 44, pp.763-774, (2001).

DOI: 10.1299/jsmec.44.763

[11] M. Feng, K. Ono, and M. Kenji, The FEM Analysis of Dry Contact in the Variable Torque Slipping Clutch with Skewed Rollers by Using Weighted Simplex and BFGS Methods, ASME Journal of Mechanical Design, Vol. 125, pp.186-199, (2003).

DOI: 10.1115/1.1543979

[12] M. Feng, K. Ono, M. and Kenji, Stress Analysis of a New Disk-Type Variable Torque Slipping Clutch with Skewed Rollers, JSME International Journal Series C, Vol. 46, pp.1509-1522, (2003).

DOI: 10.1299/jsmec.46.1509

[13] M. Feng, K. Ono, and M. Kenji, Mixed EHL Analysis of the Variable Torque Slipping Clutch with Skewed Rollers, ASME Journal of Tribology, Vol. 125, pp.756-769, (2003).

DOI: 10.1115/1.1575773

[14] Y. Miyake, H. Suzuki, K. Imagawa, and S. Obara, Study of Skewed Roller Slipping Damper for Space, Proceeding of International Symposium on Space Technology and Science, ISTS 2004-c-41, (2004).
