Oscillation Characteristic of Single Free Piston Engine Generator

Abstract:

An oscillation model of a single free piston engine generator which is coupled with a linear generator is presented in this paper. Based on the dynamics and energy equilibrium, the oscillation model is described by the mass spring damping system. It demonstrates that the generator could be regarded as a single freedom self-exited vibration system. The excitation is the periodical combustion in the cylinder. And the system reaches a limit loop after several cycles. The frequency and amplitude characteristics with the effects of key variables are shown. It provides a power map as function of the stiffness and mass, which will be applied into the match design and optimization.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 1873-1878
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.1873
• Online since: November 2011
• Authors: Chun Lai Tian, Hui Hua Feng, Zheng Xing Zuo
• Keywords: Dynamic, Free Piston Engine Generator, Oscillation, Single Piston Engine

References

[1] R. Mikalsen and A. P. Roskilly, A review of free-piston engine history and applications, Applied Thermal Engineering, 2007, vol. 27, no. 14-15, p.2339–2352.

DOI: 10.1016/j.applthermaleng.2007.03.015

[2] N. N. Clark, T. I. McDaniel, R. J. Atkinson, S. Nandkumar, C. M. Atkinson, S. Petreanu, C. J. Tennant, and P. Famouri, Modeling and development of a linear engine, in American Society of Mechanical Engineers, Internal Combustion Engine Division, vol. 30. ASME, 1998, p.49.

DOI: 10.1109/pesw.1999.747434

[3] W. M. Arshad, P. Thelin, T. Backstrom, and C. Sadarangani, Use of transverse-flux machines in a free-piston generator, Industry Applications, IEEE Transactions, 2004, vol. 40, no. 4, p.1092–1100.

DOI: 10.1109/tia.2004.830791

[4] Z. Xu and S. Chang, Prototype testing and analysis of a novel internal combustion linear generator integrated power system, Applied Energy, 2010, 87: 1342-1348.

DOI: 10.1016/j.apenergy.2009.08.027

[5] D. Carter and E. Wechner, The free piston power pack: Sustainable power for hybrid electric vehicles, SAE Paper 2003-01-3277, (2003).

DOI: 10.4271/2003-01-3277

[6] H. Xia, Y. Pang, and M. Grimble, Hybrid modelling and control of a free-piston energy converter, " in Control Applications, 2006. CCA , 06. IEEE International Conference, 2006, p.373–378.

DOI: 10.1109/cacsd-cca-isic.2006.4776675

[7] X. Chong and Z. Zhengxing, Nonlinear model and first order approximate solultion of a free piston generator, Transactions of Beijing Institute of Technology, 2008, vol. 28, no. 11, p.966–969.

[8] R. Mikalsen and A. P. Roskilly, Performance simulation of a spark ignited free-piston engine generator, Applied Thermal Engineering, 2008, vol. 28, no. 14-15, p.1726–1733.

DOI: 10.1016/j.applthermaleng.2007.11.015

[9] J. Xiao, Q. Lia, and Z. Huang, Motion characteristic of a free piston linear engine, Applied Energy, 2010, 87: 1288-1294.

DOI: 10.1016/j.apenergy.2009.07.005
