The Research of Traveling Wave Fault-Location Methods for the 10kv Distribution Networks

Abstract:

The 10kV distribution networks have complicated geographical environment and the lines with many branches, as well as high grounding resistance at fault point, thus result the difficult of locating fault. Traveling wave fault-location methods locate fault by the time of traveling wave from fault point to receiver or wave subtraction from fault point to two sides receivers, and the advantages of the methods are fast and have high precision. This paper introduced A, B, C, E four types traveling wave fault-location methods and their characteristics. Many simulations are taken for single-phase earth fault in a 10kV power distribution line with branches. By comparing the waves reflected from normal line and the fault one, the fault distance is determined by the first distortion point. As a result, the simulations indicate that the fault-location precision meet the actual requirement, Type C traveling wave fault-location method is feasible for the fault location in distribution networks.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 2479-2483
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.2479
• Online since: November 2011
• Authors: Qiao Lin Ding, Zhen Dong Yang, Ru Jun Xu
• Keywords: 10kV Distribution Network, Fault Location, Reflected Wave, Simulation, Traveling Wave Fault-Location Methods

References

[1] Chen Ping, Ge Yaozhong, Xu Bingyin. "Modern travelling wave based fault location principle and its applications to actual fault analysis Type A principle [J], Relay, 2004, 32(2): 13-18.

DOI: 10.1109/appeec.2009.4918897

[2] Chen Ping, Ge Yaozhong, Xu Bingyin. Modern travelling wave based fault location principle and its applications to actual fault analysis -Type D principle[J] , Relay, 2004, 32(3): 13-18.

DOI: 10.1109/appeec.2009.4918897

[3] Yan Feng, Yang Qixun, Qi Zheng. Study on the fault-location methods for power distribution network based on the traveling wave theory[J] , Proceedings of CSEE, 2004, 24(9): 37-42.

[4] Xu Bingyin, Li Shengxiang, Chen Zongjun. power cable fault–detection technology[M] , machinery industry press, (1999).

[5] Chen Chongyuan, Yan Qiurong. Circuit theory: port network and uniform transmission line[M], WuHan: HuaZhong university of science and technology press, (1997).
