Component of Clathrate Hydrates Formed in CH₄-TBAB-H₂O System

Abstract:

Methane storage data of clathrate hydrates formed in ternary system, methane-tetra-n-butyl ammonium bromide-water (CH₄-TBAB-H₂O), was measured by a magnetic suspension weight adsorption instrument at the temperature of 273.64 ~ 278.23 K and the pressure of 2.01 ~ 7.07 MPa, for two concentration (20.8 wt % and 43.3 wt %) of TBAB solutions. The hydrates component was qualitatively analyzed. The results showed that the structure of CH₄-TBAB semi-clathrate hydrates was deformed at high pressure possibly due to methane molecules replacing TBAB molecules and forming structure I true methane hydrates for the 20.8 wt % TBAB solutions at 273.64 K. For 43.3 wt % TBAB solutions, at the same experimental temperature and pressure, the maximum mass fraction of methane in CH₄-TBAB-H₂O clathrate hydrates was only 1.64 wt % which was less than the ideal maximum value (3.08 wt %). It showed that for the 20.8 wt % TBAB solutions, TBAB molecules were not replaced by methane molecules but both CH₄-TBAB semi-clathrate hydrates and structure I true methane hydrates were formed simultaneously. For 43.3 wt % TBAB solutions, the reason of low methane storage capacity may be that the pressure was not high enough.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 2883-2888
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.2883
• Online since: November 2011
• Authors: Liang Yang, Shuan Shi Fan, Xue Mei Lang, Yan Hong Wang, Dan Dan Bi
• Keywords: Clathrate Hydrate, Component, Tetra-N-Butyl Ammonium Bromide

References

[1] E. D. Sloan, Clathrate hydrates of natural gases, 2nd ed., Marcel Dekker, New York, (1998).

[2] P. Englezos, Clathrate hydrates, Ind. Eng. Chem. Res., 1993, 32 (7), 1251-1274.

DOI: 10.1021/ie00019a001

[3] G. A. Jeffrey, J. L. Atwood, J. E. D. Davies and D. D. MacNicol (Eds. ), Inclusion Compounds, Academic Press, 1984, 1, 135–190.

[4] W. Shimada, M. Shiro, H. Kondo, S. Takeya, H. Oyama, Ebinuma, T and H. Narita, Tetra-n-butyl ammonium bromide-water (1/38), Acta Crystallographica Section C, 2005, 61, 65-66.

DOI: 10.1107/s0108270104032743

[5] M. Arjmandi, A. Chapoy and B. Tohidi, Equilibrium data of hydrogen, methane, nitrogen, carbon dioxide, and natural gas in semi-clathrate hydrates of tetrabutyl ammonium bromide, J. Chem. Eng. Data, 2007, 52, 2153-2158.

DOI: 10.1021/je700144p

[6] Y. Qin, M. Rubino, R. Auras and L. T. Lim, Use of a magnetic suspension microbalance to measure organic vapor sorption for evaluating the impact of polymer converting process, Polymer Testing, 2007, 26: 1082–1089.

DOI: 10.1016/j.polymertesting.2007.07.010

[7] S. S. Han, H. Furukawa, O. M. Yaghi and W. A. Goddard, Covalent organic frameworks as exceptional hydrogen storage materials, J. Am. Chem. Soc., 2008, 130 (35): 11580-11581. Fig. 1 Methane storage capacity of CH4-TBAB-H2O clathrate hydrates for 20. 8 wt % TBAB solutions. □, 273. 64 K; ○, 277. 20 K; △, 278. 23 K Fig. 2 Methane storage capacity of CH4-TBAB-H2O clathrate hydrates for 43. 3 wt % TBAB solutions. □, 273. 98 K.
