Influence of Pulsed Power Equipment’s Driving Manners on Launching Process of the Electromagnetic Coil

Abstract:

For improving launching velocity and efficiency of intercepting plate in active electromagnetic armor protective system, theoretically analyzing the main parameters that determine the change of electromagnetic force. Investigating the system dynamic changes in different pulsed power equipment driving manners. Combining different driving manners, the dynamic working process of the intercepting plate launcher are simulated, that adopting finite element analytic software Ansoft’s transient solution to simulate the dynamic process of intercepting plate. The maximum velocities obtained in the bipolar driving manner and in the single-polar driving manner are 12.61 m/s and 14.00 m/s respectively. Analysis shows that the effect of the electromagnetic force is not only related with the driving manners but also with the materials.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 4895-4900
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.4895
• Online since: November 2011
• Authors: Peng Sun, Bin Lei, Zhi Yuan Li, Ke Yi Zhao, Chun Long Guo
• Keywords: Active Electromagnetic Armor, Driving Manner, Electromagnetic Force, Finite Element (FE) Simulation, Pulsed Power Equipment

References

[1] Klaus Sterzelmeier, Volker Brommer, and Laurent Sinniger, Active Armor Protection—Conception and Design of Steerable Launcher Systems Fed by Modular Pulsed-Power Supply Units, IEEE TRANSACTIONS ON MAGNETICS, VOL. 37, NO. 1, JANUARY (2001).

DOI: 10.1109/20.911829

[2] CaoYanjie , Wang Chengxue, Wang Huijin, etc. Simulation of Electromagnetic Launcher of Active Electromagnetic Armor[J], IEEE RANSACTIONS ON MAGNETICS, (2008).

DOI: 10.1109/tmag.2008.2008911

[3] Zhao Keyi, Cheng Shukang. Influence of Driving Current's Wave on Accelerative Performance of Induction Coil Launcher,. IEEE TRANSACTIONS ON MAGNETICS, (2008).

DOI: 10.1109/tmag.2008.2008833

[4] Klaus Sterzelmeier, Volker Brommer, Laurent Sinniger. Active armorprotection-conception and design of steerable launcher systems fed bymodular pulsed-power supply units[J]. IEEE Trans on Mag, 2001, 37(1): 238-241.

DOI: 10.1109/20.911829

[5] Wu A Y. Parameter Studies for Traveling Wave Coaxial Launchers. IEEE Transactions on Magnetic, 1991, 27（1）: 617-622.

DOI: 10.1109/20.101105

[6] Dong Jiannian, Wu Yi, Gui Yingchun, Zhang Jun, Relationship Between Electromagnetic Force and Phase of Current in Electromagnetic Launch, High Voltage Engineering, 2007, 33(12): 105-107.

[7] Hu Jinsuo, Electromagnetic Aomor Technical Principle and Finite Element Analysis[M], Beijing: Weapon Industry Press.

[8] Liu Hongwen, Material Mechanics, Third Edition, Higher Education Press[M], 1992, pp.322-327.

[9] Wang Ying, High pulse power supply, Beijing: Atomic Energy Press.

[10] Luo Guangyao, Design and Simulation Analysis of Pulsed Magnetic Field of Storage Capacitor, High Voltage Engineering, vol. 31, no. 3, Mar. (2005).

[11] Nie Jianhong, Sun Li, Gao Hanying, Wang Youkun, The energy transform between the inductive storage and magnetizing winding[J], ELECTRIC MACHINES AND CONTROL, 2003，7(3): 198-20.
