Applied Research on the Electric Wet Effect in Optical System Design

Abstract:

In the past half century, the camera industry has developed very rapidly, which drove the optical lens and optical zoom technology to make great progress. The zoom lens’ technology principle of current mainstream optical zoom lens system is achieved by adjusting the relative position of the lens, objects and the focus. This paper takes the double-liquid zoom lens based on electric wet effect as the basis , the new zoom optical system is designed to achieve motor control without mechanical movement, then the vision correction is designed by using liquid lens, such as the correction of myopia and hyperopia, which can automatically identify the eyes degrees of myopia and hyperopia, avoid frequent replacement lens steps when optometry is done for eyes.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 4889-4894
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.4889
• Online since: November 2011
• Authors: Zhi Qin Huang, Pei Ying Quan, Jin Li Zhang
• Keywords: Electric Wet Effect, Liquid Lens, Optical Design, Optical Zoom System, Vision Correcting
