The Simulation and Research of Chaos in Current-Controlled Boost DC / DC Converter

Abstract:

For the non-linear phenomena of the switching power supply, the discrete mathematical model of current-controlled Boost DC/DC converter has been presented in this paper, according to the switch maps. The results of simulation and experiment are derived, and the variable is the current of inductor. The accuracy of the model has been verified by the results of simulation and experiment which reveales the DC / DC converters from the bifurcation and eventually to the phenomenon of chaos. The theoretical basis using or avoiding chaos is provided for the power supply design.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 553-557
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.553
• Online since: November 2011
• Authors: Wang Zhen, Xue Feng Liu
• Keywords: Boost Converter, Chaos, Current-Controlled, Experiment, Simulation

References

[1] Wu Jie, Liu Mingjian, and Yang Ping, Study of Bifurcation and Chaos in the Current-Mode Controlled Buck-Boost DC-DC Converter (I) -Modeling and Simulation, Control Theory & Applications, vol. 19, pp: 35-38, 2002(in Chinese).

DOI: 10.1109/iecon.2001.975866

[2] Soumitor Banerjee, and GeorgeC. Verqhese, Nonlinear Phenomena in Power Electronics: Bifurcation, Chaos, Control, and Applications, Wiley-IEEE Press, July (2001).

[3] M.D. Bernardo, Discrete-Time Maps for the Analysis of Bifurcations and Chaos in DC/DC Converter, IEEE Trans. Circuits Syst., vol. 47, pp: 130—142, (2000).

DOI: 10.1109/81.828567

[4] D.C. Hamill, J.H.B. Deane, and D, J. Jefferies, Modeling of chaotic dc—dc converters by iterated nonlinear mapping, IEEE Trans. Power Electronics, vol. PE-7, pp: 25-36, (1992).

DOI: 10.1109/63.124574

[5] Dragan Maksimovic, Aleksandar M. Stankovic, Modeling and Simulation of Power Electronic Converters, Proceedings of the Ieee, vol. 89, No. 6, pp: 902-906, June (2001).
