Design and Simulation of Variable Speed Constant Frequency Brushless Doubly Fed Wind Power Generator

Abstract:

Brushless Doubly-fed Machine (BDFM) is a new inverter-driven induction motor, and it has broad prospects in wind power generation. This paper analyses the structure and VSCF electricity generating principle of a cascade Brushless Doubly fed Wind Power Generator, deduces the BDFG’s mathematical model, The variable structure control (VSC) was used to the active and reactive power decoupling control of the BDFM, analysis the relation of electromagnetism and energy balance .Finally, simulation and analysis of the whole system and control strategy are carried through in matlab/simulink soft. According to these results, the correct of parameters and simulation model for BDFM is proved.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 537-542
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.537
• Online since: November 2011
• Authors: Kai Jun Wu, Yan Yan Wang
• Keywords: Brushless Doubly Fed, Variable Speed Constant Frequency, Wind Power Generation

References

[1] Wang Qi, Chen Xiao-hu. VSCF Brushless Doubly-fed Wind Power Generation System Connected to Grid. Journal of NanJing University of Science and Technology, 2008(10).

DOI: 10.1109/drpt.2008.4523823

[2] Yang Yuan-kan, Hui Jing. Control strategy and realization of variable speed wind turbine with a brushless doubly-fed reluctance machine. Electric machines and control, 2007(7).

DOI: 10.1109/iemdc.2007.383652

[3] Z. Chen, E. Spooner. Grid interface options for variable-speed permanent magnet generator. IEE Proceeding on Electric Power Applications, 2001, 145 (4): 237-283.

DOI: 10.1049/ip-epa:19981981

[4] Wang Zheng, et al. Study on equivalent circuit of doubly fed brushless reluctance machine based on frequency referring. ICEMS'2005, 599-602.

DOI: 10.1109/icems.2005.202600
