Heat Exchanger Optimization Analysis of Aircraft Environmental Control System

Abstract:

An entropy generation analysis method based on the second law of thermodynamics was used to component level optimization design of aircraft environmental control system in this paper. Through analyzing the air flow process in environmental control system, the function relationship between system entropy generation and present initial conditions was achieved. Along with the heat exchanger design calculation process, as the bleed air pressure and cabin design temperature change, the effect of the ratio between the heat exchanger heat side flow length, cold side flow length and height on whole system entropy generation was obtained. The results obtained in this paper have some guidance function on aircraft environmental control system optimum design.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 5536-5541
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.5536
• Online since: November 2011
• Authors: Hong Bo Li, Xin Min Dong, Jun Guo, Yong Chen, Ting Ting Li
• Keywords: Entropy, Environmental Control System (ECS), Exergy, Heat Exchanger

References

[1] LU Duo. Integrated Aircraft Subsystem, In: Aviation Technology, 2003, 6, 24-26.

[2] Munoz, J. D., Optimization Strategies for the Synthesis/Design of Highly Coupled, Highly Dynamic Energy Systems, Ph.D. Dissertation, Faculty of Virginia Polytechnic Institute and State University, Blacksburg, VA, (2000).

[3] Moorhouse, D. J., Proposed System-Level Multidisciplinary Analysis Technique Based on Exergy Methods, Journal of Aircraft, Vol. 40, No. 1, Jan-Feb 2003, pp.11-15.

DOI: 10.2514/2.3088

[4] Szargut, J., David, R. M., and Steward, F., Exergy analysis of thermal, chemical, and metallurgical processes, Hemisphere Publishing Corporation, New York, NY, (1988).

[5] Bejan, A. and Siems, D. L., The Need for Exergy Analysis and Thermodynamic Optimization in Aircraft Development, Exergy, Vol. 1, No. 1, 2001, pp.14-24.

DOI: 10.1016/s1164-0235(01)00005-x

[6] Farrokh Issacci, Richard Traci. Integrated Thermal Management of Advanced Aircraft, UAI-98-002, (1998).

[7] R. S. Figliola, Robert Tipton. An Exergy-Based Methodology for Decision-Based Design of Integrated Aircraft Thermal Systems. AIAA 2000-01-5527, (2000).

DOI: 10.2514/6.2000-5527

[8] Jose V.C. Vargas, Adrian Bejan. Thermodynamic optimization of finned crossflow heat exchangers for aircraft environmental control systems. International Journal of Heat and Fluid Flow, 2001. 22: 657-665.

DOI: 10.1016/s0142-727x(01)00129-1

[9] HE Jun, ZHAO Jingquan, YUAN Xiugan. Entropy Generation Minimization Analysis for Aircraft Environmental Control System Optimal Design, In: Journal of Beijing University of Aeronautics and Astronautics, 2006, 9 : 1007-1010.

[10] T. Kuppan. Heat exchanger design manual (translated by QIAN Songwen, LIAO Jingyu etc. ). Beijing, China Petrifaction Press, (2004).
