Optimal Orthogonal Design for Herringbone Wells Injection and Production Parameters of Steam Stimulation in Heavy Oil Reservoir

Abstract:

Herringbone wells can effectively increase the exposed area of oil layer, increase reservoir producing degree, and extend the steam swept volume, ultimately to enhance recovery. The result of steam stimulation depends on injection-production parameters. This paper studies the six injection-production parameters including steam quality, steam injection rate, steam injection pressure, soaking time, cyclic steam injection volume and the maximum lifting rate, and considers the interaction among steam quality, steam injection rate and steam injection pressure. Using visual analysis and variance analysis to analyze the test results, the optimal combination of injection-production parameters were obtained, and the various factors were sorted according to their impact on the cumulative oil steam ratio. Research shows that the impact of interaction is not significant. The results of orthogonal numerical test can provide a theoretical guidance for herringbone wells injection-production parameter analysis optimization of steam stimulation in the field, and also have some practical significance.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 5791-5795
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.5791
• Online since: November 2011
• Authors: Yue Tian Liu, Wen Huan Gu
• Keywords: Heavy Oil Reservoir, Herringbone Welsl, Injection-Production Parameters, Orthogonal Numerical Test, Steam Stimulation, Variance Analysis, Visual Analysis

References

[1] YI Faxin, YU Chen, LI Songbin, ZHU Taihui, Application of herringbone multilateral horizontal well in heavy oil reservoirs, Petroleum Exploration and Development, vol. 35, pp.487-491, August 2008. (in Chinese).

[2] LI Jing, WANG Xin, SONG Chaohui, Herringbone Multilateral Wells Drilling Technology for Shallow Heavy Oil Reservoirs in Xinjiang Oilfield, , Petroleum Drilling　Techniques, vol. 35, pp.11-14, March 2007. (in Chinese).

[3] CHENG Ziyan, SHI Junping, SUN Jianfang, JIANG Ping, Optimization of Fish-bone Lateral Horizontal Wells for Thermal Recovery of Heavy Oil in 1st Sand Formation of the Lower Member of Guantao Formation in Block Zhan18, , Journal of Oil and Gas Technology, vol. 30, pp.113-115.

[4] YU Xiance, GUO Boyun, SPE 120579, A Comparison between Multi-Fractred Horizontal and Fishbone Wells for Development of Low-Permesbility Fields, presented at SPE Asia Pacific Oil and Gas Conference and Exhibition, Jakarta, Indonesia, August (2009).

[5] A.S. Dossary, A.A. Mahgoub, SPE/IADC 85307, Challenges and Achievements of Drilling Maximum Reservoir Contact (MRC) Wells in Shaybah Field, presented at SPE/IADC Middle East Drilling Technology Conference & Exhibition, Abu Dhabi, UAE, October (2003).

DOI: 10.2118/85307-ms

[6] Steven Fipke, Adriano Celli, SPE/IADC 112638, The Use of Multi-lateral Well Designs for Improved Recovery in Heavy Oil Reservoirs, presented at IADC/SPE Drilling Conference, Orlando, Florida, U.S.A., March (2008).

DOI: 10.2118/112638-ms

[7] CHEN Minfeng, LANG Zhaoxin, MO Xiaoguo, Optimization of Steam Soaking Parameters and Determination of Feasible Developing Limit for Heavy Oil Reservoir, , Journal of the University of Petroleum, China, vol. 26, pp.39-42.

[8] GAO Haihong, CHENG Linsong, YE Xingshu, Orthogonal Numerical Test of Injection and Production Parameter Optimization of Steam Flooding in Heavy Oil Reservoirs, , Journal of Oil and Gas Technology, vol. 31, pp.116-119, April, 2009. (in Chinese).

[9] B. Hascakir, A.R. Kovscek, SPE 132608, Reservoir Simulation of Cylic Steam Injection Including the Effects of Temperature Induced Wettability Alteration, presented at western Regional Meeting, Anaheim, California, USA, May (2010).

DOI: 10.2118/132608-ms
