Simulation of NN-Based MRAC for PMSM in AC Drive Mining Truck

Abstract:

Permanent magnet synchronous motor (PMSM) is a multi-variables, non-linear and strong coupling system. A model reference adaptive controller (MRAC) for PMSM based on back propagation (BP) neural network (NN) is proposed to solve the shortcoming of traditional proportion integration (PI) control method, which is widely used in linear system. According to the proposed method, the simulation model is established and simulated with Simulink. The adaptive control of motor speed is achieved with the training of BP neural network. Simulation results show that the system has long response time, small overshoot and high static performance.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 7251-7257
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.7251
• Online since: November 2011
• Authors: Yong Li, Xiao Long Zhao, Fei Ma, Yu Ting Wang
• Keywords: AC Drive, BP Neural Network (BPNN), Mining Truck, MRAC, Permanent Magnet Synchronous Motor (PMSM)

References

[1] Guoshan Chen. Mine Lifting and Transportation [M]. Beijing: Metallurgy Industry Press, (2009).

[2] GE Transportation corporation website. http: /www. getransportation. com/na/en/index. html.

[3] Chengyuan Wang, Jiakuan Xia, Junyou Yang, Yibiao Sun. Modern control technique of motor [M], Beijing: China machine press, (2006).

[4] Xiuhe Wang. Permanent Magnet Motor [M]. Beijing: China Electric Press, (2007).

[5] Bimal K. Bose, Modern power electronics and AC drives [M], Beijing: China machine press, (2006).

[6] Wei Xie. Simulation of electric and AC drive system [M]. Beijing: China Machine Press, (2009).

[7] Baoquan Kou, Shukang Cheng. AC servo motor and its control [M]. Beijing: China Machine Press, (2008).

[8] Heng Dong, Hui Wang, Keyuan Huang. Design of PMSM Drive System Digital PI Adjuster Parameters [J]. ELECTRIC DRIVE, 2009, 39(1): 7-10.

[9] Yibiao Sun, Qingding Guo. Sliding mode control based on neural network command compensator for AC permanent magnet linear servo system [J]. Transactions of China Electrotechnical society, 2002, 17(6): 21-25.

DOI: 10.1109/icmech.2005.1529257

[10] Yong Li, Fei Ma, Shunxin Chen, Yaodong Yang. PMSM simuation for AC drive in mining dump truck. The Ninth International Conference on Information and Management Sciences (IMS2010) [C], Urumchi, China, August 11-19, 2010: 321-325.

[11] Qingding Guo, Chengyuan Wang, Meiwen Zhou, et al. Precision control in linear AC servo system[M] . Beijing : China Machine Press, (2000).

[12] Yibiao Sun, Qingding Guo. Permanent magnet linear servo system control based on neural network and sliding mode [J]. Journal of Shenyang University of Technology, 2002, 24(5): 399-403.

DOI: 10.1109/icmech.2005.1529257

[13] Joohn Sheok Kim, Senng Ki Sul. Simulation of MRAS based speed sensorless estimation of induction motor drives using MATLAB/SIMUL INK [J]. IEEE Transactions on Magnet CNF, 2006, (11): 411-415.

DOI: 10.1109/pecon.2006.346686

[14] Limei Wang, Qingding Guo. Princip les and imp lamentation of permanent magnet synchronous motor zero-speed sensor less Control [J]. IEEE Transactions on Energy Conversion, 2002: 247-250.

DOI: 10.1109/amc.2004.1297940
