High-Definition Imaging and Processing System Based on CMOS Image Sensor

Abstract:

A high-definition imaging and processing system is presented, which consists of a color CMOS image sensor, SRAM, CPLD and DSP. The CPLD implements the logic and timing control to the system. SRAM stores the image data, and DSP controls the image acquisition system through the SCCB. The timing sequence of the CMOS image sensor OV9620 is analyzed. The imaging part and the high speed image data memory unit are designed. The hardware design of the imaging system and processing algorithm are given. Because the CMOS digital cameras use color filter arrays to sample different spectral components, such as red, green, and blue, at the location of each pixel only one color sample is taken, and the other colors must be interpolated from neighboring samples. We use the edge-oriented adaptive interpolation algorithm for the edge pixels and bilinear interpolation algorithm for the non-edge pixels to improve the visual image quality. This method can get high processing speed, decrease the computational complexity, and effectively preserve the image edges.

• Periodical: Advanced Materials Research (Volumes 393-395)
• Pages: 131-134
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.393-395.131
• Online since: November 2011
• Authors: Wei Ling Wang
• Keywords: CMOS Image Sensor, High-Definition Imaging, Image Processing, Interpolation Algorithm

References

[1] Qingyou Wang: Image Sensor Application Technology, Publishing House of Electronics Industry, Beijing, 2003, in Chinese.

[2] N. Stevanovic, M. Hillegrand, B.J. Hostica, and A. Teuner: A CMOS image sensor for high speed imaging, in ISSCC Tech. Dig., vol. 43, 2000, p.104–105.

[3] J. E. Adams Jr: Interactions between color plane interpolation and other image processing functions in electronic photography, Proc. SPIE, vol. 2416, 1995, p.144–151.

DOI: 10.1117/12.204825

[4] H. J. Trussell and R. E. Hartwig: Mathematics for demosaicking, IEEE Trans. Image Processing, vol. 3(11), 2002, p.485–492.

DOI: 10.1109/tip.2002.999681

[5] Ramanath R., and Snyder, W.E., Bilbro, G.L. , and Sander III, W. A: Demosaicking methods for Bayer color arrays, J. Electron. Imaging, vol. 11(3), 2002, pp.306-315.

DOI: 10.1117/1.1484495

[6] Xiongwei Zhang, Liang Chen: Principle and development application of DSP, Publishing House of Electronics Industry, Beijing, 2006, pp.147-213. in Chinese.

[7] Yun-sheng Yan, Hong-feng Jia: Digital Signal Processors: Architectures, Implementations and Applications, Publishing House of Tsinghua University, Beijing, 2005, pp.157-175. in Chinese.

[8] S. O. Memik, A. K. Katsaggelos, and M. Sarrafzadeh: Analysis and FPGA Implementation of Image Restoration under Resource Constraint, IEEE Trans. on Computers, vol. 52(3), 2003, pp: 390–399.

DOI: 10.1109/tc.2003.1183952

[9] B. K. Gunturk, Y. Altunbasak, and R. M. Mersereau: Color Plane Interpolation Using Alternating Projection, IEEE Trans. Image Processing, vol. 11(9), 2002, p.997–1013.

DOI: 10.1109/tip.2002.801121
