Study the Effect of Junction Temperature on the Peak Wavelength in GaN-Based High-Power Green Light Emitting Diodes

Abstract:

The junction temperature of GaN-based high-power green light emitting diodes is measured using the temperature coefficients of the diode forward voltage, from changes in temperature and changes in drive current to measure the LED junction temperature and the corresponding spectral, Respectively. Experiments show that, junction temperature due to environmental temperature increased, and the red shift of the spectral peak wavelength. When low temperature or less then the rated current range, the drive current increased in junction temperature rise due to the spectral peak wavelength blue shift . When the current is increased in the range of close to or greater than the rated current, leading to the junction temperature rise will cause spectral red shift . The peak wavelengths’ shift degree of 0.0579nm / k, 0.0751 nm / k and-0.1974nm / k, -0.0915 nm / k are calculated in both cases. The phenomenon is due to the LED junction temperature increases lead to band gap shrinkage, and the result of the role of spontaneous polarization and piezoelectric polarization in Ⅲ-nitride semiconductor materials.

• Periodical: Advanced Materials Research (Volumes 399-401)
• Pages: 1034-1038
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.399-401.1034
• Online since: November 2011
• Authors: Rong Rong Zhuang, Ping Cai, Jiang Li Huang
• Keywords: GaN-Based, Junction Temperature, Peak Wavelength, Power-LED

References

[1] Yu Binhai, Wang Yaohao: Chinese Journal of Luminescence. Vol. 26(2005), p.761(in chinese)

[2] Han Youl Ryu, Kyoung-Ho Ha et al: Appl Phys Lett. Vol. 87(2005), 093506.

[3] Xi Y,Xi J Q ,Gessmann Th et al: Jpn J Appl Phys , Vol. 44(2005), pp.7260-7266.

[4] Chen Haiyan, Zhao Guanghua,Zhao Fuli: Acta Scientiarum Naturalium Universitatis Sunyatseni.Vol.48(3)(2009), p.38(in chinese)

[5] Arturas Zukauskas,Michael S.Shur, Remis Gaska: Introduction to Solid-State Lighting, Beijing: Chemical Industry Press,2006, p.61(in chinese)

[6] Lou Yi,Gou Wenping,Shao Jiaping et al :J,Acta Phys .Vol. 53(2004), p.2721(in chinese)

[7] Chhajed S , Xi Y, Th Gessmann , et al: Proc SPIE. 5739 ,pp.16-24.

[8] LIN Qiao-ming,GUO Xia: Semiconductor Opto Electronics. Vol.28(3) ,P.338-341(in chinese)
