MEST of Round Blooms with Different Foot Roll Pitch Designing for Peritectic Steel Casting

Abstract:

The minimum mould exit shell thickness (MEST) is one of key factors to consider for continuous casting machine design. Based on the shell strength at elevated temperatures, a concept of shell integral average strength, from its very top surface to the solidus frontier, has been introduced to judge its bulging tendency under ferrostatic pressure. Considering the contribution for the foot roller designing, a mathematic model for the determination of the minimum MEST has been brought forward. It is shown that, when the minimal foot roll pitch is fixed, the minimum MEST is steady. But at the same time, when the MEST does not exceed the minimum value, the round bloom off-round would happen, it is worse for the round bloom than the bulging for the normal strand. And there is the cross point with the curve of the minimum MEST by the minimum roll pitch and the minimum MEST by the fluting include angle of the support roller and the lateral support roller against the cross section.

• Periodical: Advanced Materials Research (Volume 402)
• Pages: 147-150
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.402.147
• Online since: November 2011
• Authors: Li Gen Sun, Hui Rong Li, Li Guang Zhu
• Keywords: Continuous Casting, Foot Roller Designing, Minimum Mould Exit Shell Thickness, Round Bloom

References

[1] Cui Lixin, Three Dimensional Thermo-mechanical Model of Continuously Cast Slab with Dynamic Soft Reduction[M]，Doctor thesis of USTB, 2005.12.28 ( in Chinese )

[2] Sumio Kobayashi, Tsuneaki Nagamichi and Koki Gunji. Numerical analysis of solute redistribution during solidification accompanying δ / γ transformation, Transaction ISIJ [J], 1988, 28: 543.

DOI: 10.2355/isijinternational1966.28.543

[3] Gunter Funk, Jurgen R. Bonmer, Franz N. Fett and Robert Hentrich. Coupled thermal and stress-strain models for the continuous casting of steels, Steel Research [J], 1993, 64 （5）：246.

DOI: 10.1002/srin.199301017

[4] ZHU Boqin, Zhou Jingqin, Xu Zheming. Construntion Mechanics [M], Shanghai：Tongji University Press 2004.3 ( in Chinese ).

[5] HUANG Meng-sheng, ZHAO Yin. Engineering Mechanics[M], Beijing：Tsinghua University Press2006.9. ( in Chinese )

[6] Chunsheng Li, B. G. Tomas. Thermomechanical Finite-Element Model of Shell Behavior in Comtinuous Casting of Steel. Met. and Mat. Trans. B [J], 2004, 35B: 1151.

[7] SunLigen, Cui Lixin, Zhang Jiaquan. Minimum mould exit shell thickness of blooms for peritectic steel casting, Journal of Iron and Steel Research International, 2008.11, suppl: 297

DOI: 10.4028/www.scientific.net/amr.421.179
