A Fully Integrated S-Band Power Amplifier in 0.35um-SiGe BiCMOS Technology

Abstract:

A fully integrated S-band high efficiency power amplifier using the TSMC 0.35 um SiGe BiCMOS technology is presented. The two-stage power amplifier has been optimized for the whole S-band covering 2 GHz to 4 GHz frequency band for higher 1-dB compression point and efficiency. The input and output matching networks are designed on chip. From the simulate result, the two-stage power amplifier achieves high PAE of 28% and saturation output power of 23.3 dBm at 3 GHz, with the small signal gain of 18.7 dB. Besides, this PA realizes the PAE within the band of 2.4GHz to 4GHz exceed 25%, and the highest PAE of 30.6% at 3.4 GHz.

• Periodical: Advanced Materials Research (Volumes 403-408)
• Pages: 2481-2484
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.403-408.2481
• Online since: November 2011
• Authors: Kang Li, Guo Dong Huang, Xiao Feng Yang, Qian Feng, Chao Xian Zhu, Chi Liu
• Keywords: Power Added Efficiency, Power Amplifier, S-Band, Si-Ge HBT

References

[1] M. Kaynak, I. Tekin, Y. Gurbuz: Realisation of a single-chip, silicon germanium: C-based power amplifier for multi-band worldwide interoperability for microwave access applications. IET Microw. Antennas Propag. 2010, Vol. 4, Iss. 12, p.2273–2280, April (2010).

DOI: 10.1049/iet-map.2009.0438

[2] Yan-Jun Peng, Jia-You Song, Zhi-Gong Wang: A 3. 3V SiGe HBT Power Amplifier for 5GHz WLAN Application. Solid-State and Integrated Circuit Technology, 2006. ICSICT06. 8th, International Conference 1541-1543.

DOI: 10.1109/icsict.2006.306282

[3] Ping-Sung Chi, Zuo-Min Tsai, Jing-Lin Kuo, Kun-You Lin, and Huei Wang: An X-band, 23. 8-dBm Fully Integrated Power Amplifier with 25. 8% PAE in 0. 18-μm CMOS Technology. Proceedings of the 5th European Microwave Integrated Circuits Conference 27-28 September 2010, Paris, France.

DOI: 10.1109/apmc.2008.4958262

[4] Hwann-Kaeo Chiou, Ping-Chun Yeh, Kuei-Cheng Lin: High performance SiGe HBT power unit-cell for S-Band open collector adaptive bias power amplifier design. Solid-State Electronics 52 (2008) 239–244, August (2007).

DOI: 10.1016/j.sse.2007.08.017

[5] Hsin-Hsing Liao, Hao Jiang, Payman Shanjani, Joseph King, and Arya Behzad: A Fully Integrated 2×2 Power Amplifier for Dual Band MIMO 802. 11n WLAN Application Using SiGe HBT Technology. IEEE JOURNAL OF SOLID-STATE CIRCUITS, VOL. 44, NO. 5, MAY (2009).

DOI: 10.1109/rfic.2008.4561489

[6] Thomas J. Farmer, Ali Darwish, and Mona E. Zaghloul: A 2. 4 GHz SiGe HBT High Voltage/High Power Amplifie. IEEE MICROWAVE AND WIRELESS COMPONENTS LETTERS, VOL. 20, NO. 5, MAY (2010).

DOI: 10.1109/lmwc.2010.2045595

[7] T. H. Lee: The Design of CMOS Radio-Frequency Integrated Circuits . Cambridge University Press, Cambridge, (1998).

[8] John Rogers, Calvin Plett: Radio Frequency Integrated Circuit Design. Artech House microwave library, London, (2003).
