Fuzzy Adaptive Hysteresis Band Current Controller for Solar Photovoltaic Inverter

Abstract:

Photovoltaic inverters are important solar energy application. This paper presents a novel Fuzzy Adaptive Hysteresis Current Controller to control the inverter, used in the non-linear time-variant solar photovoltaic cell. The proposed controller has the advantages of both fuzzy as well as adaptive controller. It is capable of reducing the total harmonic distortion and to provide acceptable switching frequency. The mathematical model of Photovoltaic array is developed using the Newton’s method using the parameter obtained from a commercial photovoltaic data sheet under variable weather conditions, in which the effect of irradiance and temperature are considered. The modeled Photovoltaic array is interfaced with DC-DC boost converter, AC-DC inverter and load. A DC-DC boost converter is used to step up the input DC voltage of the Photovoltaic array while the DC-AC single-phase inverter converts the input DC comes from boost converter into AC. The performance of the proposed controller of inverter is evaluated through MATLAB-Simulation. Unlike standard adaptive controller designs, this adaptive fuzzy controller does not require an explicit mathematical model of the system. The results obtained with the proposed algorithm are compared with those obtained when using conventional fixed hysteresis current controller for single-phase photovoltaic inverter in terms of THD and switching frequency.

• Periodical: Advanced Materials Research (Volumes 403-408)
• Pages: 4991-4999
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.403-408.4991
• Online since: November 2011
• Authors: D. Devaraj, S. Sakthivel, K. Punitha
• Keywords: Boost Converter, Fuzzy Adaptive Hysteresis Controller, Photovoltaic Inverter
