Robust Adaptive Fuzzy Logic Controllers for Intelligent Universal Transformers in ADA

Abstract:

Intelligent Universal Transformer (IUT) will comprise in Advanced Distribution Automation (ADA) with a new invention in control and management in future. It evolves with a high speed traditional transformer in addition to power electronic base construction will eventuate to oil elimination, dimensional size and weight reduction. Adaptive Fuzzy Logic Control (AFLC) is an adaptive progressed method with the high system performance capability being raised even on the uncertainty conditions. It enhances system stability, improves flexibility and releases designers from precise mathematical model utilization. Expert designer Knowledge is a critical requirement for conventional fuzzy logic controller (FLC), in contrast the AFLC rules and parameters are generated by adaptive model and human knowledge will downright initialize the first parameters values. In this approach four layers IUT topology is considered for developing the end user service options as 48V DC, reliable power as 240V AC 400HZ and three phase power option. AFLC schemes are proposed for employing current and voltage controllers in input output stages. Real time voltage regulation, automatic sag correction, Harmonic Filtering, energy storage option and dynamic system monitoring are the resulting benefits of using IUT four layers topology. AFLC methodology, leading the system robustness in any cases of grid and load disturbances.

• Periodical: Advanced Materials Research (Volumes 403-408)
• Pages: 5038-5044
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.403-408.5038
• Online since: November 2011
• Authors: Maryam Sadeghi, Majid Gholami
• Keywords: ADA, AFLC, DER, FLC, IED, IUT, Membership Function, Power Electronic

References

[1] C. Elmasa, O. Deperlioglu, H. H. Sayan, Adaptive fuzzy logic controllerfor DC–DC converters, Expert Systems with Applications jurnal, 2009, PP. 1540–1548.

DOI: 10.1016/j.eswa.2007.11.029

[2] H. Akagi, The next generation medium voltage power conversion systems, Journal of the Chinese Institute of Engineers, (2007).

[3] EPRI Report 1010915, Technical and System Requirements for Advanced Distribution Automation, (2004).

[4] S. Ratanapanachote, Application of an electronic Transformer in a power distribution system, Texas A&M University, (2004).

[5] EPRI Product ID # 1009516, Feasibility Study for the Development of High-Voltage, Low-Current Power Semiconductor Devices, 2003 Strategic Science and Technology Project.

[6] F. Goodman, Intelligent Universal Transformer Technology Development , EPRI (2006).

[7] IEEE Power Engineering Society, Research Plan for Advanced Distribution Automation, General Meeting , (2005).

[8] M. Mc. Granaghan, F. Goodman, Technical and System Requirements for Advanced Distribution Automation, 18th International Conference on Electricity Distribution, CIRED, Turin, 6-9 June (2005).

DOI: 10.1049/cp:20051374

[9] I.M.Y. O, Single-chip fuzzy logic controller design and anapplication on a permanent magnet dc motor, Engineering Applications of Artificial Intelligence jurnal, 2005, PP. 881–890.

DOI: 10.1016/j.engappai.2005.03.004

[10] J. H. Park, G. T. Park, Robust adaptive fuzzy controller for non-affine nonlinear systems with dynamic rule activation, Int. J. Robust Nonlinear Control 2003; PP 117–139.

DOI: 10.1002/rnc.717

[11] H. Krishnaswami, V. Ramanarayanan, Control of high-frequency AC link electronic‏ transformer, Indian Institue of Sience, (2005).

[12] D. Wang, C. Mao, J. Lu, S. Fan, F. Peng, Theory and application of distribution electronic power transformer, Electric Power Systems Research Journal, vol 77, 2007, pp.219-226.

DOI: 10.1016/j.epsr.2006.02.012

[13] H. Iman-Eini, , JL. Schanen, Sh. Farhangi, J. Barbaroux, JP. Keradec, A Power Electronic Based Transformer for Feeding Sensitive Loads , IEEE , (2008).

DOI: 10.1109/pesc.2008.4592324

[14] A. Hefner, Silicon-Carbide Power Devices for High-voltage, high-Frequency Power Conversion, National Institute of Standards and Technology, Gaithersburg, (2007).

[15] D. Aggler ,J. Biela , J.W. Kolar, Solid State Transformer based on Sic JFETs for Future Energy Distribution Systems.

[16] A. Maitra, A. Sundaram, M. Gandhi, S. Bird, Sh. Doss, Intelligent Universal Transformer Design and Applications, CIRED 20th International Conference on Electricity Distribution, Prague, 8-11 June (2009).

DOI: 10.1049/cp.2009.1129

[17] Energy and Environmental Economic Inc, Value of Distribution Automation applications prepared, (2007).

[18] S. Ratanapanachote, Applications of an electronic transformer in a power distribution system, A Dissertation submitted to Texas A&M University, August (2004).

[19] Marc C. Robbinson, Solid state Universal Intelligent Transformer.

[20] J. S. Lai,A. Maitra,A. Mansoor,F. Goodman, Multilevel Intelligent Universal Transformer for medium voltage applications, IEEE Industry Application Conf., (2005).

DOI: 10.1109/ias.2005.1518705

[21] F. Goodman, Intelligent Universal Transformer Technology Development , EPRI (2006).

[22] A Maitra & A Sundaram, Universal Intelligent Transformer Design and applications, Power Distribution Conference , (2009).

[23] N. A. Gounden, S. A. Peter, H. Nallandula, S. Krithiga, Fuzzy logic controller with MPPT using line-commutated inverter for three-phase grid-connected photovoltaic systems, journal of Renewable Energy, 2009, vol 34, PP. 909–915.

DOI: 10.1016/j.renene.2008.05.039
