Precision Generating Cutting Research of Rectangle Spline Based on Parameters Superposition

Abstract:

Aiming at the precision generating cutting problem of rectangle spline shaft, the multi-parameter fusion method to modified cutting edge of rectangle spline hob is presented. The method based on the analysis of workpiece machining errors to establish a fusion model about the rectangle spline hob cutting parameters and the rectangle spline shaft deformation quantity, the model can indicate the connection between rectangle spling hob theoretics profile and actual cutting profile, therefore, the rectangle spline hob’s profile is modified and to simulate by polynomials. The simulation experiment indicates that the method exact approximation the hob’s modified profile. Compare with the methods of the double-circular-arc and the least square fitting, the multi-parameter fusion method can enhance both design precision and design efficiency.

• Periodical: Advanced Materials Research (Volume 411)
• Pages: 117-120
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.411.117
• Online since: November 2011
• Authors: Jian Jun Jia, Hong Xi Wang, Ling Wang
• Keywords: Machining Deformation, Parameters Superposition, Profile Modification, Rectangle Spline Hob

References

[1] E. Creighton, A. Honegger, A. Tulsian, D, Mukhopadhyay, Analysis of thermal errors in a high-speed micro-milling spindle, J. International Journal of Machine Tools & Manufacture. 50 (2010) 386-393.

DOI: 10.1016/j.ijmachtools.2009.11.002

[2] G. Totis, G.Wirtz, M.Sortino, D.Veselovac, E.Kuljanic, F.Klocke, Development of a dynamometer for measuring individual cutting edge forces in face milling, J. Mechanical SystemsandSignalProcessing. 2 (2010) 1–14.

DOI: 10.1016/j.ymssp.2010.02.010

[3] Hua J, Umbrello D, Shivpuri R, Investigation of cutting conditions and cutting edge preparations for enhanced compressive subsurface residual stress in the hard turning of bearing steel, J. Mater Process Technol. 171 (2006) 180-187.

DOI: 10.1016/j.jmatprotec.2005.06.087

[4] Matsumoto Y, Hashimoto F, Lahoti G, Surface integrity generated by precision hard turning, J. Ann CIRP. 48 (1999) 59-62.

DOI: 10.1016/s0007-8506(07)63131-x

[5] Tao Xiaojie, Research on Hobbing Errors and Its ComPensation Technique. Hefei University of Technology, Hefei, 2005.

[6] Qiu Liangheng, XinYixing, Wang Tong, Jiang Son, A Calculation of Bulk Temperature and Thermal Deflection Of Gear Tooth about Profile Modification, J. Journal of Shanghai Jiaotong University. 29 (1995) 79-86.

[7] Jia Jianjun, Yu Xiaoning, Simulation and Design of Rectangle Spline Hob's Profile Based on BP Neural Network, J. Tool Engineering. 43 (2009) 64-67.

[8] Jia Jianjun, Li Jian, Simulating and design of the irregular cutting edge with BP neural network J. WISM. 1 (2009) 261-264.

DOI: 10.1109/wism.2009.61

[9] Wang Xinzhong, Error analysis in the rectangle multiple-spline fabricating process, J. Mechanical Research & Application. 19 (2006) 42-43.
