Application of Stress Intensity to Design of Bi-Materials with a Wedge

Abstract:

Failure in anisotropic/isotropic bi-materials starts at the interface, and the interfacial failure is of interest to some engineering fields such as automobile and aviation industry. Many researchers have done a lot of research on this field, but many did not consider a specific stress component near the interface corner tip as a parameter of a failure criterion. Kun Cheol Shin, introducted a failure criterion for anisotropic/isotropic bi-materials problem with a wedge. But the process of obtaining the singular stress fields of anisotropic/isotropic bi-materials is complex. To solve this problem, we have taken a new method which is from Xuecheng-Ping and M.-C. Chen.The method is new, which is based on displacement and more easily in calculating the stress and displacement fields surrounding a wedge tip than before. Through this method, we establish a criterion base on the-plan. The failure criterion can be used not only to predict stress intensities of co-cured double lap joints that with thermal and mechanical load, but also to predict stress intensities of co-cured double lap joints that with different materials or lap length. And we describe the process of calculating singular stress fields and stress intensities of co-cured double lap joints with a wedge that consists of glass fiber reinforced composites and steel adherends.

• Periodical: Advanced Materials Research (Volume 413)
• Pages: 223-228
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.413.223
• Online since: December 2011
• Authors: Xue Cheng Ping, Xing Li, Xiao Xiang Xu
• Keywords: Anisotropic Bi-Material, Isotropic Bi-Materials, Stress Intensity Factor (SIF), Wedge

References

[1] Kum Cheol Shin, Won Seock Kim, Jung Ju Lee, Application of Stress intensity to design of anisotropic/isotropic bi-materials with a wedge, Internation Journal of Solids and Structures 44(2007) 7748-7766.

DOI: 10.1016/j.ijsolstr.2007.05.014

[2] M. -C. Chen, K.Y. Sze, A novel hybrid finite element analysis of biomaterial wedge problems, Engineering Fracture Mechanics 68(2001) 1463-1476.

DOI: 10.1016/s0013-7944(01)00015-7

[3] Byers, 1987 WC Carpenter and C. Byers, A path independent integral for computing stress intensities for v-notched cracks in a bi-material, Int. J. Fract. 35 (1987), p.245–268.

DOI: 10.1007/bf00276356

[4] Choet al., 1994 YJ Cho, HG Beom and YY Earmme, Application of a conservation integral to an interface crack interacting with singularities, Int. J. Fract. 65 (1994), p.63–73.

DOI: 10.1007/bf00017143

[5] Chue 2002 CH Chue and CI Liu, Stress singularities in a bi-material anisotropic wedge with arbitrary fiber orientation, Comp. Struct. 58 (2002), p.49–56.

DOI: 10.1016/s0263-8223(02)00041-7
