Dynamics Analysis and Simulation of one-DOF Parallel Manipulator

Abstract:

One-degree of freedom (DOF) parallel manipulator of sorting robot is of vital importance for municipal solid waste (MSW) sorting. The motion velocity of the manipulator is very high. So the inertia forces seriously affect the motion characteristics of the manipulator. In order to solve this problem, this paper makes force analysis for the manipulator by using method of body-separation. In the process of the force analysis, the inertia forces are took into account. The dynamics equations of the manipulator are established based on D’Alember’s principle and dynamics sequence solution. The sequence to solve all the equations is listed. Dynamics simulation of one-DOF parallel manipulator is made to visualize the solved results of the equations by using software ADAMS.

• Periodical: Advanced Materials Research (Volume 422)
• Pages: 47-50
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.422.47
• Online since: December 2011
• Authors: Mei Fa Huang, Guang Qian, Wei Zhao Luo, Lei Lei Chen, Guo Cai Jin
• Keywords: Body-Separation, Dynamic Analysis, Parallel Manipulator, Simulation

References

[1] Xiuquan Qu, Hongbo Li and Qingxin Meng: Journal of Harbin Institute of Technology, Vol. 38(2006), p.1673(In Chinese).

[2] Fengxia Zhu, Zhiwei Tong and Zhongli Huang: Coalmine Machinery, Vol. 30(2009), p.83(In Chinese).

[3] Zhenghao Ge: Advanced Materials Research, Vol. 199-200(2011), p.275.

[4] Mingxing Zhu: Journal of Hunan University of Science & Technology (Natural Science Edition), Vol. 25(2010), pp.29-31 (In Chinese).

[5] Xurong Li: Advanced Materials Research, Vol. 189-193, p.1882(2011).

[6] Yiyong Yang and Dewen Jin: Mechanical System Dynamics (Tsinghua University press, China 2009).
