The Establish of Digital Simulation System on Continuous Cross-Flow Dryer

Abstract:

Drying plays an important role in the post-harvesting process of grain, and the quality of the corn after drying has received an increasing concern. The mathematical model of grain drying plays an essential role in developing grain dryer structure and obtaining the drying technological parameters. Furthermore, an accurate mathematical model is a reference for automated control during drying process. In this paper, using mathematical models and quality model of the corn drying process, a digital simulation of corn drying machine system based on a virtual instrument was established for 5HSZ dryer. Finally, an on-line measurement and automated control software of grain parameters were developed providing the changes of moisture, temperature, humidity, and germination rate in the process of drying. The experimental results show that the simulation result is valid, which has practical merit of operation and technical optimization of dryer.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 1759-1763
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.1759
• Online since: January 2012
• Authors: Feng Han, Chun Cheng Zuo, Hang Zhu, Wen Fu Wu, Chun Shan Liu
• Keywords: Dryer, Grain Drying, Model, Virtual Instrument (VI)

References

[1] Liu Xueqiang. Complexity analysis and process control for grain drying[D]. Changchun: Jilin University, (2006).

[2] Liu Q, Bakker-Arkema F W. A model-predictive controller for grain drying[J]. Journal of Food Engineering. 2001, 49: 321-326.

DOI: 10.1016/s0260-8774(00)00229-6

[3] Cao Yanming, Li Changyou. Software Programming for a Control System of Grain Dryer with Circulation and Tempering [J]. Transactions of the Chinese Society of Agricultural Machinery. 2003, 34(1): 83-85.

[4] Mellmann J, Teodorov T. solids transport in mixed-flow dryers[J]. Powder Technology. 2011, 205: 117-125.

DOI: 10.1016/j.powtec.2010.08.073

[5] Liu Q, Bakker-Arkema F W. Automatic control of crossflow grain dryers, Part 1: Development of a process model[J]. Journal of Agricultural Engineering Research. 2001, 80(1): 81-86.

[6] Helge D. Model based predictive control of a rotary dryer[J]. Chemical Engineering Journal. 2002, 86: 53-60.

[7] Hu Zhichao, Wang Haiou, Xie Huanxiong, et al. Mathematical models and model predictive control for crossflow grain drying[J]. Transactions of the CSAE, 2009, 25(4)：96-102.

[8] Cao Chongwen, Zhu Wenxue. Computer simulation of agricultural drying process [M]. Beijign: China Agriculture Press, (2001).

[9] Wu Wenfu, Xia Yanhui, Zhaoxuedu, et al. Predictive Model for Post-dried Seed Viability by Its Super-weak Bioluminescence [J]. Transactions of the Chinese Society of Agricultural Machinery. 2003, 34(2): 43-46.

[10] Wu Wenfu. Study on Quality Control Principles and Methods of Drying Maize [D]. Changchun: Jilin University, (2002).
