Analysis on Degree of Freedom and Singularity of Mechanism Based on Topological Graph Theory

Abstract:

Based on the analysis of current developing state of graph theory, define the description of spacial moving capability of common couples and translation base and rotation base of mechanism, based on the new description method in topological graph theory. DOF(degree of freedom) of hybrid mechanism analysised with example based on the definition of dimensionity of branch spacial moving capability and mechanism spacial moving capability, necessary and sufficient condition of nonsingularity of mechanism presented, as well as the necessary and sufficient condition of singularity of mechanism deduced , in-phase and assimilation condition and in-phase and dissimilarity condition and asynchronism condition of limitation of input base of branch adopted, case number of position singularity and pose singularity and position and pose singularity obtained then, still the way of founding the combination and case number of common serial mechanism and parallel mechanism and hybrid mechanism mentioned.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 1943-1946
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.1943
• Online since: January 2012
• Authors: Jian Guo Luo, Mao Yan He
• Keywords: Degree of Freedom, Graph Theory, Mechanism, Set, Singularity

References

[1] F. Freudenstein, L. Dobrjanskyj: Congress of Applied Mechanics Vol. 12(1964), p.420.

[2] K. D. Lu: Graph theory and its application(TsinghuaUniversity Publishing House, Beijing1984).

[3] H. F. Ding, Z. Huang, submitted to Journal of Mechanical Engineering(2007), in Chinese.

[4] M. Grübler: Allgemeine Eigenschaften der zwangläufigen ebenen kinematische (Civilingenieur, Verhandlungen1883).

[5] M. Grübler: Allgemeine Eigenschaften der zwangläufigen ebenen kinematische (Civilingenieur, Verhandlungen1885).

[6] K. Kutzbach: Einzelfragen aus dem gebiet der Maschinenteile(Zeitschrift der Verein Destscher, Ingenieur1933).

[7] C. H. Suh, C. W. Radcliffe: Kinematics and Mechanisms Design(Prentice Hall, New York1978).

[8] G. N. Sandor, A. G. Erdman: Advance Mechanism: Analysis and Synthesis(Prentice Hall, New York1984).

[9] Z. Huang, Y. S. Zhao and T. S. Zhao: High level spacial mechanics(High Education Publishing House, Beijinig 2006) , in Chinese.

[10] T. L. Yang: Basic theory on configuration and kinematics and kinetics of machinery system(Machinery Industry Publishing House, Beijing1995) , in Chinese.

[11] T. S. Mruthyunjaya: Journal of Mechnism and Machine Theory Vol. 41 (2003), pp.23-25.

[12] Z. Y. Chang, C. Zhang and Y. H. Yang, et al.: Journal of Mechnism and Machine Theory Vol. 40 (2002), pp.158-163.

[13] J. G. Luo, M. Y. He and Z. Lu, et al.: Journal of Mechanical Engineering Vol. 44 (2008), pp.65-69, in Chinese.
