Experimental Study on Nitrogen-Spray Water Quenching for 9SiCr

Abstract:

Alloy steel 9SiCr is quenched by a certain proportion of mixture gas of nitrogen and spray water at atmosphere, and the continual cooling curve during quenching is determined, the rigidity of quenched workpiece is measured and the metallographic map is captured. The results show that it can improve the cooling effect of quenching medium on the one hand; on the other hand, it can decrease the deformation and residual stress of workpieces. The results show that the rigidity of quenched workpiece is about 62 (HRC), which is corresponding with the rigidity after oil quenching. Martensite phase transformation occurs at the end of quenching that can be seen from the metallographic map.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 365-368
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.365
• Online since: January 2012
• Authors: Bao Dong Shao, Li Feng Wang, He Ming Cheng, Rui Jie Wang, Jian Yun Li, Zi Liang Li, Li Jun Hou, Jie Hou, Chong Tian, Dong Fang Ding
• Keywords: Gas Quenching, Metallographic Map, Nitrogen-Spray Water Mixture, Rigidity

References

[1] CHENG H. M., XIE J. B., LI J. Y., Comparison of properties of 9SiCr alloy steel in various quenching media after quenching. Journal of Aeronautical Materials, vol.24, No.4, (2004) 14-17.

[2] SHAO B D, CHENG H M, LI J Y, et al, The effect of the structure of collection loop on two-phase flow field in quenching furnace. International Conference on Measuring Technology and Mechatronics Automation, Shanghai, China, (2010)1245-1249

[3] SHAO B D, CHENG H M, LI J Y, et al, Numerical simulation of complex flow field in quenching furnace by mixture of Nitrogen-spray water eject quenching. 2010 International Conference on Future Industrial Engineering and Application, Shenzhen, China, (2010) 75-78

[4] Faura F., Campo A., Zamora B., A mixture of pure gases that produce maximum heat transfer characteristics for quenching. J. Mater. Eng. Perf., vol.7, No.3, (1998) 420-424.

DOI: 10.1361/105994998770347873

[5] Laumen C., Midea S. J., Lubben T., Hoffmann F. and Mayr P., Measured heat transfer coefficients by using hydrogen as quenchant in comparison with helium and nitrogen, In SM heat treatment conference. Accelerated Cooling/Direct Quenching of Steels. Indianapolis, Indiana, USA, (1997) 199-206.

[6] MEI G H, MENG H J, WU R Y, CI Y, XIE Z, Analysis of spray cooling heat transfer coefficient on high temperature surface. Energy for Metallurgical Industry, vol.23, No.6, (2004)18-22.

[7] GAO S, QU W, YAO W, Flow and heat transfer of droplet impinging on hot flat surface during spray cooling. Journal of Engineering Thermophysics, vol.28, suppl.1, (2007) 221-226.

[8] LIU Z H, Experimental study on the boiling critical heat flux of mist cooling. Journal of Shanghai Jiaotong University, vol.31, No.2, (1997) 61-65, in Chinese.
