A Novel Index to Voltage Collapse based on the System Physical Quantities

Abstract:

This paper presents a new index to voltage collapse based on the system physical quantities such as nodes' voltages and injected powers.The index has a critical value. It is physically meaningful, varies smoothly when the system changes (i.e. does not exhibit discontinous changes on value for small system changes such as oLTCs´action). This new index does not need to build any models and not be limited with load patterns.Moreover it can be used to real time system monitoring because it can be easily calculated , and can alert operators to take appropriate actions. The simulate result is very promising.

• Periodical: Advanced Materials Research (Volumes 433-440)
• Pages: 6060-6064
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.433-440.6060
• Online since: January 2012
• Authors: Zhi Wei Sun, Xiao Liu
• Keywords: Performance Indices, Voltage Collapse

References

[1] Edwin Lerch, Ein Neues Verfahren zur Robusten Loesung Stationaerer Arbeitspunktprobleme im Elektrischen Energienetz, Doctor paper, (1984).

[2] CIGRE TF 38-02-11, Indices predicting voltage collapse including dynamic phenomena. December (1994).

[3] Prabha kundur et al. Voltage stability assessment, procedures and guides, IEEE/PES Power system stability subcommittee special publication, January (1999).

[4] Prabha Kundur, Power System Stability and Control, McGraw-Hill, Inc., New York, (1994).

[5] P. A. Lf, T. Smed, G. Anderson, and D .J. Hill, Fast calculation of a voltage stability index, IEEE Trans. Power Systems, vol. 7, no. 1, February 1992, pp.54-64.

DOI: 10.1109/59.141687

[6] B. Gao, G. k. Morrison, and P. Kundur, Voltage stability evaluation using modal analysis, IEEE Trans. Power Systems, vol. 7, no. 4, November 1992, pp.1529-1542.

DOI: 10.1109/59.207377

[7] O. O. Obadina,G. J. Berg, Determination of voltage stability limit in multimachine power systems, IEEE Trans. on Power Systems, vol. 3, no. 4, 1988, pp.1545-1554.

DOI: 10.1109/59.192964

[8] T. Van Cutsem, A method to compute reactive power margins with respect to voltage collapse, IEEE Trans. Power on Systems, vol. 6, no. 1, February 1991, pp.145-156.

DOI: 10.1109/59.131057

[9] V. Ajjarapu, N. Jain, Z. Yu, and S. Battula, Resent development to the continuation power flow, Proc. NAPS, Washington, DC, October 1993, pp.205-214.

[10] C. A. Canizares, A. Z. de Souza, and V. H. Quintana, Comparison of performance indices for detection of proximity to voltage collapse, IEEE Trans. Power Systems, vol. 11, no. 3, August 1996, pp.1441-1450.

DOI: 10.1109/59.535685

[11] A. C. Z. de Souza et al. Critical bus and point of collapse determination using tangent vectors, Proc. NAPS, M.I.T., November 1996, pp.329-333.

[12] C. D. Vournas, Voltage stability and controllability indices for multimachine power systems, IEEE Trans. Power System, vol. 10, no. 3, August 1995, pp.1183-1194.

DOI: 10.1109/59.466538
