A Generalized Compensation Strategy for Dynamic Voltage Restorer

Abstract:

Dynamic voltage restorer (DVR) is used to mitigate the impact of the voltage sags. At first the structure of DVR and three basic compensation methods are introduced. Considering the compensation performance and the injection capability of the DVR, a generalized compensation strategy based on pre-fault compensation, energy-saving compensation and progressive phase rotation method is proposed. With this compensation strategy, the active power injected by DVR can be minimized on the premise of the quality of compensation. Simulation results demonstrate the efficacy of the proposed compensation strategy.

• Periodical: Advanced Materials Research (Volumes 433-440)
• Pages: 7253-7260
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.433-440.7253
• Online since: January 2012
• Authors: Chang Bin Ke, Yong Li Li, Bo Tong Li, Qiang Jin
• Keywords: Dynamic Voltage Restorer (DVR), Generalized Compensation Strategy, Progressive Phase Rotation Method, Voltage Sag

References

[1] M. F. Mcgranaghan, W. C. Roettger, The economics of custom power, Proceedings of the 2003 IEEE PES Transmission and Distribution Conference and Exposition. Dallas, TX, USA, Vol. 3, p.944~948, Sep. (2003).

DOI: 10.1109/tdc.2003.1335065

[2] N. Abi-Samra, A. Sundarm, The role of distribution system dynamic voltage restorer in enhancing the power at sensitive facilities, Proceedings of Western Electronics Show Convention. Anaheim. CA. USA, p.167~181, Oct. (1996).

DOI: 10.1109/wescon.1996.553984

[3] R. Affolter, B. Connell, Experience with a dynamic voltage restorer for a critical manufacturing facility, Proceedings of the 2003 IEEE PES Transmission and Distribution Conference and Exposition. Dallas, TX, USA, Vol. 3, p.937~939, Sep. (2003).

DOI: 10.1109/tdc.2003.1335063

[4] S. S. Choi, B. H. Li, D. M. Vilathgamuwa, Dynamic voltage restoration with minimum energy injection, IEEE Trans on Power Systems, vol. 15(1), p.51~57, Feb. (2000).

DOI: 10.1109/59.852100

[5] B. H. Li, S. S. Choi, D. M. Vilathgamuwa, A new control strategy for energy-saving dynamic voltage restoration, Proceedings of 2000 Power Engineering Society Summer Meeting. Piscataway. NJ. USA, vol. 2, p.1103~1108, Jul. (2000).

DOI: 10.1109/pess.2000.867532

[6] S. S. Choi, J. D. Li, D. M. Vilathgamuwa, A generalized voltage compensation strategy for mitigation the impact of voltage sags/ swells, IEEE Trans on Power Delivery, vol. 20(3), p.2289~2297, Jun. (2005).

DOI: 10.1109/tpwrd.2005.848442

[7] D. M. Vilathgamuwa, A. PERERA, S. S. Choi, Voltage sag compensation with energy optimized dynamic voltage restorer, IEEE Trans on Power Delivery, vol. 18(3), p.928~936, Jul. (2003).

DOI: 10.1109/tpwrd.2003.813880

[8] X. M. Feng, R. G. Yang, Analysis of voltage compensation strategies for dynamic voltage restorer (DVR), Automation of Electric Power Systems, vol. 28(6), p.68~72, Feb. (2004).

[9] C. Yuan, H. G. Yang, Advanced minimum energy control of dynamic voltage restorer, Automation of Electric Power Systems, vol. 28 (21), p.49~53, Nov. (2004).

[10] X. J. Zhang, C. Yang, Z. Tang, B. Liu, Y. D. Han, The voltage injection analysis in series power quality controller, Proceedings of the CSEE, vol. 23 (2), p.15~20, Feb. (2003).

[11] J. G. Nielsen, F. Blaabjerg, N. Mohan, Control strategies for dynamic voltage restorer compensating voltage sags with phase humps, Proceedings of IEEE Applied Power Electronics Conference and Exposition. Anaheim. CA. USA, vol 2, p.1267~1273, Mar. (2001).

DOI: 10.1109/apec.2001.912528
