Dynamic Fatigue Simulation of Engine Block Based on Virtual Prototype Technology

Abstract:

This paper carried out simulation analysis on the dynamic fatigue strength of an inline six-cylinder engine block based on the measured indicator diagram by the means of virtual prototype technology. A 3D solid model of the crankshaft block system is established firstly. After that, based on finite element method, dynamic stress of the block under operating conditions is obtained, by the means of Multi-body dynamics method. Then, calculation analysis on the fatigue safety coefficient of the engine block is made.
