Research on Dynamic Characteristic and Experiments of Double-Disc Rotor System with Oil Film Support

Abstract:

Multi-DOF model of double-disc rotor-bearing system taking oil film support into account is established, and Newmark method is also applied to dynamic response of continuous system. To simplify the calculation in double-disc eccentric situation, the research aims at time domain, frequency response and bifurcation solution, simultaneously qualitative experiments are also carried out on the experiment bench. Experiments show that the numerical algorithm and calculation results are credible. The conclusions conclude: For the rotor system shown in the paper, with the other parameters constant, small eccentricity system is prone to appear quasi-periodic instability, but for big eccentricity system it is period-doubling instability, and the instability speed will increase with eccentricity enlargement; initial eccentric phase has severe effects on the dynamic characteristic of system, so it is worth studying it more in depth. This method and results in this paper provides a theoretical reference for stability analysis and vibration control in more complex relevant rotor-bearing system.

• Periodical: Advanced Materials Research (Volume 442)
• Pages: 235-239
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.442.235
• Online since: January 2012
• Authors: Chao Feng Li, Jie Liu, Qin Liang Li, Bang Chun Wen
• Keywords: Dynamic Characteristic, Experiment, Finite Element Model (FEM), Oil Film, Rotor-Bearing System

References

[1] Zheng Tiesheng, Wu Xiaohong. Complex Non-linear Rotor - Numerical Analysis in Dynamic Characteristic of Bearing System. Journal of Mechanics, Vol. 33 (2001), p.377.

[2] P. Sundararajan, S. T. N. An Algorithm for Response and Stability of Large Order Non-Linear Systems - Application to Rotor Systems. Journal of Sound and Vibration, Vol. 214 (1998), p.695.

DOI: 10.1006/jsvi.1998.1614

[3] T. Zheng, N. H. Nonlinear Dynamic Behaviors of A Complex Rotor-bearing System. Journal of Applied Mechanics, Vol. 67 (2000), pp.485-495.

DOI: 10.1115/1.1286208

[4] Jing J P, Meng G, Sun Y, et al. On the Nonlinear Dynamic Behavior of A Rotor-bearing System. Journal of Sound and Vibration, Vol. 274 (2004), p.1031.

[5] Cui Ying, Liu Zhansheng. 200MW Turbine Generator Rotor - Research in Nonlinear Stability of Bearing System. Journal of Mechanical Engineering, Vol. 41 (2005), p.170.

[6] Adiletta G, Guido A R, Rossi C. Chaotic Motions of A Rigid Rotor in Short Journal Bearings. Nonlinear Dynamics, Vol. 10(1996) , p.251.

DOI: 10.1007/bf00045106

[7] Li Chaofeng, Dai Jishuang, Wen Bangchun. The Periodic Motion Stability and Bifurcation of Double-disc Rotor-bearing System with Oil Film Support. Journal of Mechanics, Vol. 43 (2011), p.208.

[8] Liu Changli, Yao Hongliang, Li He, et al. Research in Periodic Motion Stability and Experiment of Rub-impact Cracked Rotor-bearing. Journal of Applied Mechanics, Vol. 21 (2004), p.52.

[9] Li Z. P., Wen B. C. Study on Complex Nonlinear Dynamics of Rigid Rotor - Bearing System. Journal of Vibration and Shock, Vol. 24 (2005), p.36.
