Design and Control of a Mini Quad-Rotor UAV Based on Embedded System

Abstract:

In this paper, one kind of quad-rotor UAV (unmanned aerial vehicle) controller is designed according to analyze its structure and function. The hardware platform is established based on DSP MC56F8037, inertial sensor unit, as well as facilities that make it suitable for the dynamic system. According to the analysis of the working principle of the quad-rotor, the nonlinear dynamic model is established. This is a hierarchical embedded model based control scheme that is built upon the concept of backstepping, the simulation result shows the controllers are valid. This realization makes a great progress in the development process of a more advanced realization of an UAV suitable for practical applications.

• Periodical: Advanced Materials Research (Volume 442)
• Pages: 477-481
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.442.477
• Online since: January 2012
• Authors: Man Man Du, Feng Jin
• Keywords: Backstepping Method, Embedded Control, Quad-Rotor UAV

References

[1] Hongning Hou, Jian Zhuang, Hu Xia, A Simple Controller of Minisize Quad-Rotor Vehicle, International Conference on Mechatronics and Automation, Xi'an, China, (2010).

DOI: 10.1109/icma.2010.5588802

[2] Atsushi Oosedo, Atsushi Konno, Takaaki Matumoto, System Intergration(SII), (2010).

[3] I. Prinz, The Mesicopter: A Meso-Scale Flight Vehicle, http: /aero. stanford. edu/mesicopter.

[4] S. BouabdAllah, P. Murrieri, R. Siegwart, Towards Autonomous Indoor Micro VTOL, Autonomous Robots 18, 171-183, Springer Inc, (2005).

DOI: 10.1007/s10514-005-0724-z

[5] P. Ponds, R Mahony and P. Corke, Modeling and Control of Quad-Rotor Robot, In Proc of Australasian Conference on Robotics and Automation, Sydney, Australia (2005).

[6] S. Slazar-Cruz, A. Palomino, R. Lozano, Trajectory tracking for a four rotor mini-aircraft, Proceedings of the 44th IEEE conference on Decision and Control and the European Control Conference (2005).

DOI: 10.1109/cdc.2005.1582539

[7] J. Escareno, S. Salazar-Cruz, R. Lozano, Embedded control of a four-rotor UAV, Proceedings of the 2006 American Control Conference. IEEE Criteria for Class IE Electric Systems (Standards style), IEEE Standard 308, (1969).

DOI: 10.1109/acc.2006.1657333

[8] S. Bouabdallah, R. Siegwart, Backstepping and Sliding-mode Techniques Applied to an Indoor Micro Quadrotor, Proceedings of the 2005 IEEE conference on Robotics&Automation.

DOI: 10.1109/robot.2005.1570447

[9] S. Bouabdallah, P. Murrieri,R. Siegwart, Design and Control of an Indoor Micro Quadrotor, Proceedings of the 2004 IEEE conference on Robotics&Automation.

DOI: 10.1109/robot.2004.1302409

[10] Alexandros Soumelidis, P´eter G´asp´ar, Gergely Regula, Control of an experimental mini quad-rotor UAV, 16th Mediterranean Conference on Control and Automation Congress Centre, Ajaccio, France, June 25-27, (2008).

DOI: 10.1109/med.2008.4602174
