Investigation of the Dynamic Behaviors of Cranes under Seismic Effects with Theoretical and Experimental Study

Abstract:

This paper is concerned with investigation of the dynamic behaviors of cranes under seismic effects. For this purpose, firstly we have performed experiment on a 1/20 scale crane model on the shake table with real earthquake data, then a multi degree-of-freedom non-linear mathematical model is developed including behavior of the container cranes under earthquakes and simulated. The simulation system has a five degrees-of-freedom and modeled system was simulated for the ground motion of the El Centro earthquake in USA, 1940. Finally, the time history of the crane bridge displacement and acceleration responses of the both theoretical and experimental cases are presented. Theoretical and experimental results exhibit that the mathematical model is accurate. This study also shows the destructive effects of high accelerations which occur during the earthquake. These effects cannot be omitted in the design of cranes. The result of this study which is an accurate mathematical model can be inspiring for the engineers in terms of design parameters.

• Periodical: Advanced Materials Research (Volume 445)
• Pages: 1082-1087
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.445.1082
• Online since: January 2012
• Authors: Ahmet Sagirli, C. Oktay Azeloglu
• Keywords: Crane, Earthquake-Induced Vibration, Non-Linear Mathematical Model, Shake Table Test, Structural Vibration

References

[1] T. Kanayama, A. Kashiwazaki. A Study on the Dynamic Behavior of Container Cranes Under Strong Earthquakes,. Seismic Engineering 364 (1998) 276-284.

[2] T. Kanayama, A. Kashiwazki, N. Shimizu, I. Nakamaura, N. Kobayashi. Large Shaking Table Test of a Container Crane by Strong Ground Excitation,. Seismic Engineering 364 (1998) 243-248.

[3] A. Otani, K. Nagashima, J. Suzuki. Vertical Seismic Response of Overhead Crane,. Nuclear Engineering and Design 212 (2002) 211-220.

DOI: 10.1016/s0029-5493(01)00483-6

[4] N. Kobayashi, H. Kuribara, T. Honda, M. Watanabe. Nonlinear Seismic Responses of Container Cranes Including the Contact Problem Between Wheels and Rails,. Journal of Pressure Vessel Technology 126 (2004) 59-65.

DOI: 10.1115/1.1636786

[5] E. Soderberg, M. Jordan. Seismic Response of Jumbo Container Cranes and Design Recommendations to Limit Damage and Prevent Collapse,. ASCE Ports 2007 Conference San Diago CA. (2007).

DOI: 10.1061/40834(238)105

[6] B. Koshab, L. Jacobs. Seismic Performance of Container Cranes,. Seismic Risk Management for Port Systems NEESR Grand Challenge Third Annual Meeting Georgia Institute of Technology Atlanta GA (2008).

[7] L. Jacobs, R. DesRoches, R.T. Leon. Shake Table Testing of Container Cranes, The 14th World Conference on Earthquake Engineering 14th WCEE Beijing China, (2008).

[8] T. Sugano, M. Takenobu, T. Suzuki, Y. Shiozaki. Design Procedures of Seismic-Isolated Container Crane at Port,. The 14th World Conference on Earthquake Engineering 14th WCEE Beijing China (2008).

[9] A. Sagirli, C.O. Azeloglu, R. Guclu, H. Yazici. Self-tuning Fuzzy Logic Control of Crane Structures against Earthquake Induced Vibration,. Nonlinear Dynamics 64 (2011).

DOI: 10.1007/s11071-010-9868-2
