Analytical Method for Temperature Distribution in Buried HDPE Pipe

Abstract:

HDPE pipes have been widely used in industry, which were mostly buried underground. Because of special material properties, which were affected by temperature, it is necessary to get the temperature profile of buried HDPE pipe. Most past solutions for temperature distribution in buried pipe were numerical ones. The aim of this paper was to present a simple analytical model under steady-state heat transfer condition with a new special heat transfer coefficient introduced. FEM method was used to check this model. The influences of fluid temperature, soil surface temperature and soil depth on pipeline temperature were also analyzed. The results showed a good agreement between the analytical model and FEM method. And fluid temperature in pipe was proved to be the key factor that affected the pipe temperature .

• Periodical: Advanced Materials Research (Volumes 452-453)
• Pages: 1205-1209
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.452-453.1205
• Online since: January 2012
• Authors: Zheng Li, Hong Wu Zhu, Pin Xian Qiu, Abdennour Seibi
• Keywords: Heat Transfer Coefficient (HTC), Temperature Distribution, Thermal Resistance

References

[1] D. V Reddy. Long-term performance of buried high density polyethylene plastic piping. Florida Department of Transportation; (2005).

[2] E. Hahne and U. Grigull, A shape factor scheme for point source configurations. int. J. Heal Mass Transfer, 17, 267-273 (1974).

DOI: 10.1016/0017-9310(74)90088-x

[3] E. R. G. Eckert and R. M. Drake, Analysis of Heat and Mass Transfer. p.98 and 340. McGraw-Hill (1972).

[4] N. N. Lebedev, I. P. Skalskaya and Y. S. Uflyand, Worked Problems in Applied mathematics. pp.212-213. Dover (1979).

[5] R. Thiyagarajan and M. M. Yovanovich, Thermal resistance of a buried cylinder with constant flux boundary condition, Trans. Am. Soc. Mech. Engrs. Series C, J. Heat Transfer 96, 249-250 (1974).

DOI: 10.1115/1.3450174

[6] Haim H. Bau, Heat losses from a fluid flowing in a buried pipe, Int.J. Heat Mass Transfer. Vol. 25, No. 11, pp.1621-1629, (1982).

DOI: 10.1016/0017-9310(82)90141-7

[7] I. A. foffe, A problem of transient heat conduction in a semi-bounded body with an internal heat source. Inzh. Fiz. Zh. 23, 351-355 (1972). English translation: J. Engng Phys. 23, 1051-1054 (1972).

DOI: 10.1007/bf00828846

[8] W. W. Martin and S. S. Sadhal, Bounds on transient temperature distribution due to a buried cylindrical heat source, Int. J. Heat Mass Transfer 21, 783-789 (1974).

DOI: 10.1016/0017-9310(78)90040-6

[9] I.T. Al-Zaharnah , Conjugate heat transfer in fully developed laminar pipe flow and thermally induced stresses, Comput. Methods Appl. Mech. Engrg. 190 (2000) 1091-1104.

DOI: 10.1016/s0045-7825(99)00467-3

[10] Antuan Negiz, Three-dimensional transient heat transfer from a buried pipe-I. laminar flow, Chemical Engineering Science, Vol. 48, No. 20, pp.3507-3517, (1993).

DOI: 10.1016/0009-2509(93)85006-b

[11] Godwin A. Chukwu, P.E.: Department of Energy, Study of Transportation of GTL Products From Alaskan North Slope (ANS) To Markets , (2002).

DOI: 10.2172/808065

[12] Dipl. Ing. Jan Hansen-Schmidt. Modelling of Oil Pipeline Networks, submitted to the 2008 Conference on Student Creativity and Invention, (2008).

[13] A.F. Mills, Basic Heat and Mass Transfer: Prentice Hall, 1999: 395-396.
