A Study of Contact Stress on Coatings of Wheel-Slide Using ANSYS

Abstract:

The main purpose of this research is to find a solution for the coating/substrate of the wheel-slide which is the key component of civil aircraft flaps and slats, firstly, the simulation test is designed based on wheel-slide’ s working environment. Further, stress analysis of the coating/substrate is researched, and the results are as the input parameters of the finite element model. Then the finite element software, ANSYS, is applied to simulate the contact stress of coating/substrate in wheel-slide, and the stress’s distribution of coating/substrate are analyzed under different load, different coating thickness, different elastic modulus ratio of coating and other parameters. So the stress field characteristics are gained to guide the conduct of modeling experiments. The results can be applied to explore the failure of mechanism coating/substrate system, and provide theoretical guidance to design the coatings.

• Periodical: Advanced Materials Research (Volumes 452-453)
• Pages: 175-179
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.452-453.175
• Online since: January 2012
• Authors: Jing Cai, Yi Ming Xu, Hai Bin Lin
• Keywords: ANSYS, Coating, Contact Stress, Wheel-Slide

References

[1] Gu Ming. The design of experiment for the needle bearing of civil aircraft's flap [D]. Nanjing University of Aeronautics and Astronautics, (2008).

[2] Luo Ji-wei. Analysis on stress in rolling bearing and its Development [J]. BEARING, , 01(9): 8～31.

[3] Chen Jun-Wei. Research on measurement and control system of wear test machine for slide of the civil aircraft flap [D]. Nanjing University of Aeronautics and Astronautics, 2010. 3.

[4] Zhou Zheng . The finite element analysis of fretting contact stress on hard coating of ceramic wear-resistant. [D]. Shandong University, 2006. 5.

[5] The third maschinery industry ministry 640 institute . 《Aviation material standard manual metal part》. The third machinery industry ministry 640 institute, 1976. 6.

[6] Zhang Xian-Cheng. Basic researches on the structural integrity and life prediction of plasma-sprayed coating based systems aiming for remanufacturing [D]. Shanghai Jiao Tong University. 2007. 6.

[7] YOSHIDA A, FUUJII M. Influence of soft surface modification on rolling contact fatigue strength of machine element[J]. Tribology International, 2002, 35(12): 837～847.

DOI: 10.1016/s0301-679x(02)00068-3

[8] K. Kaddouri,M. behouari,B. Bachir Bouiadjra. Finite element analysis of crack perpendicular to bi-material interface[J]. Computational Materials Science, 2006, 35: 53～60.

DOI: 10.1016/j.commatsci.2005.03.003

[9] Demirhan. Necdet, Kanber. Bahattin. Stress and Displacement Distributions on Cylindrical Roller Bearing Rings Using FEM[J]. Mechanics Based Design of Structures & Machines, 2008, 36(1): 86～102.

DOI: 10.1080/15397730701842537
