Cu (II), Zn (II) Complexes Containing Calix [4] Arene Modified by Salicylaldehyde Acylhydrazone - Synthesis, Properties and Application

Abstract:

Two complexes L(MAcO)₂ (M=Cu, Zn) containing calix [4] arene ligand H₂L modified by salicylaldehyde acylhydrazone have been synthesized and characterized by elemental analysis, MS(ESI), IR, UV-vis and fluorescence. Whereas L(ZnAcO)₂ exhibited an enhancement in fluorescence, the potentiality of H₂L acting as a Zn²⁺- selective fluorescence probe was investigated. Results showed that a good linearity (correlation coefficient 0.999) between fluorescence intensity and concentration of Zn²⁺ in range of 4.0×10^-6 mol·L^-1 ~ 4.0×10^-5 mol·L^-1 existed in H₂L solution of 1.0×10^-4 mol·L^-1. The minimum concentration at which H₂L could detect Zn²⁺ was 1.0 ×10^–6 mol·L^-1. Co-existence of Cu²⁺, Ni²⁺ and Mn²⁺ would interfere the determination of Zn²⁺, but no influence by Na⁺, Mg²⁺, Cd²⁺ and Pb²⁺.

• Periodical: Advanced Materials Research (Volumes 455-456)
• Pages: 1244-1250
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.455-456.1244
• Online since: January 2012
• Authors: Xiao Mei Zhang, Guo Cai Xu, Jia Long Sun
• Keywords: Complex, Cu²⁺, Salicylaldehyde Acylhydrazone Calix [4] Arene, Zn²⁺, Zn²⁺-Selective Fluorescence Probe

References

[1] S.N. Podyachev; N.E. Burmakina; V.V. Syakaev; S.N. Sudakova; R.R. Shagidullin; A.I. Konovalov. Synthesis, IR and NMR characterization and ion extraction properties of tetranonyl- calix.

DOI: 10.1016/j.tet.2008.10.008

[4] resorcinol bearing acetylhydrazone groups. Tetrahedron, 2009, 65(1): 408-417.

[2] F.M. Ramírez; J-C.G. Bünzli; S. Varbanov; J. Padilla. Physicochemical Properties and Theoretical Modeling of Actinide Complexes with a para-tert-Butylcalix.

[6] arene Bearing Phosphinoyl Pendants. Extraction Capability of the Calixarene toward f Elements. Journal of Physical Chemistry B; 2008, 112(35): 10976-10988.

DOI: 10.1021/jp710848m

[3] M. Kumar; J.N. Babu;V. Bhalla. Fluorescent chemosensor for Cu2+ ion based on iminoanthryl appended calix.

DOI: 10.1007/s10847-009-9670-2

[4] arene. Journal of Inclusion Phenomena and Macrocyclic Chemistry, 2010, 66 (1/2): 139-145.

[4] D.P. Nikolelis; G. Raftopoulou; N. Psaroudakis; G-P. Nikoleli. Development of an electrochemical chemosensor for the rapiddetection of Zinc based on air stable lipid films with incorporated calix.

DOI: 10.1002/elan.200804225

[4] arene phosphoryl receptor. International Journal of Environmental Analytical Chemistry, 2009, 89(3): 211-222.

[5] X. Wei; J.J. Vittal; R.J. Puddephatt; Anionic calixarene complexes of copper(I) and silver(I) as cation receptors. Inorganic Chemistry; 97, 36(1): 86-94.

DOI: 10.1021/ic960508w

[6] P. Kumar; Y-B. Shim. Chromium(III)-selective electrode using p-(4-Acetanilidazo) calix.

[4] arene as an ionophore in PVC matrix. Bulletin of The Korean Chemical Society, 2008, 29 (12): 2471-2476.

DOI: 10.5012/bkcs.2008.29.12.2471

[7] G. Ozturk; E.U. Akkaya. Differential and substrate-selective reactivity of calix.

[4] arene derivatives with cyclenyl-Zn(II) modifications at the upper rim. Organic letters, 2004, 6(2): 241 -243.

DOI: 10.1021/ol0360694

[8] W.P. Zhu; J. Ling; H. Xu; Z.Q. Shen. Copolymerization of trimethylene carbonate and 2, 2- dimethyltrimethylene carbonate by rare earth calixarene complexes. Polymer; 2005, 46 (19): 8379 -8385.

DOI: 10.1016/j.polymer.2005.07.007

[9] E Hoppe; C. Limberg; , B. Ziemer. Mono- and dinuclear oxovanadium (V) calixarene complexes and their activity as oxidation catalysts. Inorganic Chemistry; 2006, 45 (20): 8308-8317.

DOI: 10.1021/ic061106j

[10] R. Cacciapaglia; A. Casnati; L. Mandolini; D.N. Reinhoudt; R. Salvio; A. Sartori; R. Ungaro. Di-and trinuclear arrangements of zinc(II)-1, 5, 9- triazacyclododecane units on the calix.

DOI: 10.1016/j.ica.2006.07.024

[4] arene scaffold: Efficiency and substrate selectivity in the catalysis of ester cleavage. Inorganica Chimica Acta: 2007, 360(3): 981-986.

DOI: 10.1016/j.ica.2006.07.024

[11] J.M. Notestein; E. Iglesia; A. Katz. Photoluminescence and charge-transfer complexes of calixarenes grafted on TiO2 nanoparticles. Chemistry of Materials; 2007, 19(20): 4998-5005.

DOI: 10.1021/cm070779c

[12] I.A. Bagatin; C. Legnani; M. Cremona. Investigation on Al(III) and Zn(II) complexes containing a calix.

[4] arene bearing two 8-oxyquinoline pendant arms used as emitting materials for OLEDs. Materials science & engineering. C, Biomimetic and supramolecular systems, 2009, 29(1): 267-270.

DOI: 10.1016/j.msec.2008.06.020

[13] R.K. Pathak; Sk. Md. Ibrahim; C.P. Rao; Selective recognition of Zn2+by salicylaldimine appended triazole-linked di-derivatives of calix.

DOI: 10.1016/j.tetlet.2009.03.126

[4] arene by enhanced fluorescence emission in aqueous-organic solutions: role of terminal -CH2OH moieties in conjunction with the imine in recognition. Tetrahedron letters, 2009, 50(23): 2730-2734.

DOI: 10.1016/j.tetlet.2009.03.126

[14] D. Buccella; G. Parkin. Mononuclear and dinuclear Molybdenum and Tungsten complexes of p-tert-butyl tetrathiacalix.

[4] arene and p-tert-butyltetrasulfonylcalix.

[4] arene: Facile cleavage of the calixarene ligand framework by Nickel. Journal of the American Chemical Society; 2008, 130(27): 8617-8619.

[15] D. Buccefla; G. Parkin. p-tert-butylcalix.

[4] arene complexes of Molybdenum and Tungsten: Reactivity of the calixarene methylene C-H bond and the bacile migration of the metal around the phenolic rim of the calixarene. Journal of the American Chemical Society; 2006, 128(50): 16358 -16364.

DOI: 10.1021/ja066457b

[16] A.J. Petrella; C.L. Raston. Calixarenes as platforms for the construction of multimetallic complexes. Journal of Organometallic Chemistry; 2004, 689(24): 4125-4136.

DOI: 10.1016/j.jorganchem.2004.07.065

[17] B. Valeur; I. Leray. Ion-responsive supramolecular fluorescent systems based on multichromophoric calixarenes: A review. Inorganica Chimica Acta 2007, 360: 765-774.

DOI: 10.1016/j.ica.2006.07.027

[18] N. Kotzen; A. Vigalok. The inside of metal calixarene chemistry. Supramolecular Chemistry, 2008, 20(1-2): 129-139.

DOI: 10.1080/10610270701747057

[19] L.H. Liu; L.N. Zakharov; J.A. Golen; A.L. Rheingold; T.A. Hanna. Synthesis and characterization of Bismuth(III) and Antimony(III) calixarene complexes. Inorganic Chemistry; 2008, 47(23): 11143-11153.

DOI: 10.1021/ic801445m

[20] G. Karotsis; S. Kennedy; S.J. Dalgarno; E.K. Brechin. Calixarene supported enneanuclear Cu(II) clusters. Chemical Communications. 2010, 46 (22): 3884-3886.

DOI: 10.1039/c0cc00011f

[21] Z.X. Xu; Z.T. Huang; C.F. Chen. Synthesis and structures of novel enantiopure inherently chiral calix.

[4] arene-derived salphen ligands and their transition-metal complexes. Tetrahedron letters, 2009, 50(38): 5430-5433.

DOI: 10.1016/j.tetlet.2009.07.064

[22] D. Cuc; S. Bouguet-Bonnet; N. Morel-Desrosiers; J-P. Morel; P. Mutzenhardt; D. Canet. Location of a Metallic Cation Complexed in a Calixarene Cavity As Determined by Calixarene 13C Spin Relaxation. Application to Cesium and Thallium Complexed by p-Sulfonatocalix.

DOI: 10.1021/jp8067816

[4] arene in Water. Journal of Physical Chemistry B; 2009, 113(11): 3499-3503.

[23] Y. de Gaetano; I. Clarot; J.B. Regnouf-de-Vains. Cu(I) and Zn(II) chelations on polymer beads modified by attachment of a bipyridyl-calixarene-based chelate. Tetrahedron Letters, 2009, 50(42): 5793-5797.

DOI: 10.1016/j.tetlet.2009.07.131

[24] R. Joseph; B. Ramanujam; H. Pal; Lower rim 1, 3-di-amide-derivative of calix.

[4] arene possessing bis- {N-(2, 2- dipyridylamide)} pendants: a dual fluorescence sensor for Zn2+and Ni2+. Tetrahedron Letters, 2008, 49(43): 6257-6261.

DOI: 10.1016/j.tetlet.2008.08.049

[25] J. Dessingou; R. Joseph; C.P. Rao; A direct fluorescence-on chemo- sensor for selective recognition of Zn(II) by a lower rim 1, 3-di-derivative of calix.

DOI: 10.1016/j.tetlet.2005.09.079

[4] arene possessing bis-{N-(2- hydroxynaphthyl-l-methylimine)} pendants. Tetrahedron Letters, 2005, 46(46): 7967-7971.

DOI: 10.1016/j.tetlet.2005.09.079

[26] Y. Liu; N. Zhang , B.T. Zhao; H.Y. Zhang. Spectroscopic behavior on the formation complex of three double-armed calix.

[4] arene derivatives with lanthanoid nitrates in acetonitrile. Spectro chimica Acta PartA. 2002, 58: 2889-2895.

[27] Zhang Xiao-mei; Jiang Hai-ying; Wang Shao-bao. Synthesis and its anti-ultraviolet and anti- oxidation Activity of Calix.

[4] arene Derivative Containing Schiff-base Fraction [J]. Journal of Anhui University(Natural Sciences), 2008, 32(2): 70-73.

[28] S.N. Rao; K.N. Munshi; N.N. Rao; M.M. Bhadbhade; E. Suresh. Synthesis, spectral and X-rays tructural characterization of [cis-MoO2(L) (solv)] (L=salicylidene salicyloyl hydrazine) and its use as catalytic oxidant. Polyhedron, 1999, 18: 2491-2497.

DOI: 10.1016/s0277-5387(99)00139-4

[29] T. Ghosh; B. Mondal; T. Ghosh; M. Sutradhar; G. Mukherjee; M.G.B. Drew. Synthesis, structure, solution chemistry and the electronic effect of para substituents on the vanadium center in a family of mixed-ligand [VVO(ONO)(ON)] complexes. Inorganica Chimica Acta., 2007, 360: 1753 -1761.

DOI: 10.1016/j.ica.2006.10.003

[30] P.F. Lee; C.T. Yang; D. Fan; J.J. Vittal; J.D. Ranford. Synthesis, characterization and physicochemical properties of copper II complexes containing salicylaldehyde semicarbazone. Polyhedron, 2003, 22: 2781~2786.

DOI: 10.1016/s0277-5387(03)00402-9

[31] X.H. Chen; Q.J. Wu; Z.Y. Liang; C.R. Zhang. Synthesis, Structure, Thermal Stability and Fluorescence of One Binuclear Zn(II) Complex [Zn2(L)2(Mf)2]. Chinese Journal of Inorganic Chemistry, 2009, 25(5): 910-914.
