Virtual Impact Test for Aluminum-Alloy Wheel Based on Numerical Simulation Method

Abstract:

The mechanical properties of car wheel mast have high reliability requirements. The impact test for trial casting aluminum alloy wheel must be passed, which is one of the bench tests. Based the practical case, the integrated finite-element model for virtual test is established, including impact block, wheel, tire, bracket, rubber pad, the standard test load conditions are imposed, and the entire impact process was simulated by finite-element method, the velocity, displacement and kinetic energy curves of the impact block, the stress distribution and the impact force curve of change were obtained. Moreover, using in a typical case, compared with the physical impact test, the model and procedure of the finite-element numerical simulation was verified. The modeling method and calculation procedure given can guide the virtual design of aluminum-alloy wheel, the blindness of design can be reduced, and the development work efficiency can be increased.

• Periodical: Advanced Materials Research (Volumes 457-458)
• Pages: 93-97
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.457-458.93
• Online since: January 2012
• Authors: Ji Gang Chen, Guo Zhi Zhang
• Keywords: Aluminum-Alloy Wheel, Impact Test, Numerical Simulation Method, Virtual Test

References

[1] J. G Chen, Research on Integrated Manufacturing Information System of Aluminum Alloy Wheel, Doctoral Dissertation of Yanshan Uni., Qinhuangdao, China, 2006, pp.10-12.

[2] J.G. Chen, G.Z. Zhang, Y.F. Lin, Finite Element Model of Bending Fatigue Test of Aluminum-alloy Wheel, Journal of Engineering Design, 2 (2011) 120-125.

[3] Y.G. Shi, J.G. Chen, H. X Sun, Modeling and Application of Aluminum-Alloy Wheel Virtual Test-Bed, in: Z.C. Chen; X.J. Gu; G.N. Qu (Eds. ), Digital Enterprises And Nontraditional Industrialization, China Machine Press, Beijing, China, 2003, pp.937-940.

[4] G.Z. Zhang, The Finite-Element Numerical Simulation of The Bench Test Of Car A-Alloy Wheel, Masteral Dissertation of Yanshan Uni., Qinhuangdao, China, 2005, pp.59-61.

[5] Y.F. Mou, J.Z. Hou, The Supervision Manual of Implementing the Standard for Automotive Wheel in China, China Machine Press, Tianjin, China, 1995, pp.144-151.

[6] Standardization Administration of China. GB/T 15704-1995: The method of impact test for automotive wheel, China Machine Press, (1996).
