ZnO Thin Film Sensor Design of the Charge Amplifier

Abstract:

The ZnO film as the material, the charge amplifier and the accelerometer in one set, to record and display the measurement data directly, simplifying the testing system to improve the test accuracy and reliability. Charge amplifier circuit is designed to be simple, easy to debug, high integration, low cost, favorable ZnO thin films driven by the widespread use of the accelerometer.

• Periodical: Advanced Materials Research (Volume 462)
• Pages: 65-70
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.462.65
• Online since: February 2012
• Authors: Hui Qin Sun
• Keywords: Accelerometer, Charge Amplifier, ZnO Thin Film
