First-Ply Strength of Thick Circular Cylindrical GRP Composite Shell Subjected to Static External Pressure via Finite Element Simulation and Analytical Approaches

Abstract:

One-ply thick externally pressurized GFRP cylinders were analyzed using computational numerical simulation and analytical method. The main part of the work was to study the critical external pressure to avoid failure in the laminated shells by employing various phenomenological failure criteria. Comparison between ABAQUS FEM simulation results and analytical solutions using MATLAB programming codes proved high accuracy of the analytical approach. Various fiber angles stacking sequences were chosen for optimization analysis. The results did not show any increase in stability as the layer number increased. The results also showed high correlation with corresponding failure criteria. The analytical solutions gave higher accuracy as the number of plies and the total laminate thicknesses were reduced.

• Periodical: Advanced Materials Research (Volumes 463-464)
• Pages: 477-483
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.463-464.477
• Online since: February 2012
• Authors: Scott Gohery, Abolfazl Golshan, Mohammadhassan Hashemzadeh, Navid Hosseininezhad
• Keywords: Analytical Solution, Failure Criteria, FEM Simulation, First-Ply Strength, Laminated GFRP Cylinder, Maximum Stress Criterion, Static External Pressure

References

[1] Kulkarmi, S. V. and Zweben, C. H. (eds), composites in pressure vessels and piping. PVP-PB-021, ASME, (1997).

[2] Tauchert, T.R., Optimum design of a reinforced cylindrical Pressure Vessel. Journal of Composite. Mat. Vol: 15, pp.390-402, (1981).

DOI: 10.1177/002199838101500501

[3] Eckold, G.C., A Design method for filament wound GRP vessels and piping. Composites. Vol: 16, pp.41-47, (1985).

DOI: 10.1016/0010-4361(85)90657-3

[4] Fukunaga, H. and Uemura, M., Optimum design of helically wound Composite pressure vessels. Journal of Composite Structure. Vol: 1, p.31. 49, (1983).

DOI: 10.1016/0263-8223(83)90015-6

[5] Fukunaga, H. and Chou, T.W., Simplified design techniques for laminated cylindrical pressure vessels under stiffness and strength constrains. Journal of Composite. Mat. Vol: 22, pp.1157-1169, (1988).

DOI: 10.1177/002199838802201206

[6] Adali, S., Sumers, E.B. and Verijenko, V.E., Optimization of laminated cylindrical presser vessels under strength criterion. Journal of Composite Structure. Vol: 25, pp.305-312, (1993).

DOI: 10.1016/0263-8223(93)90177-r

[7] T. Y. Kam, Y. W. Liu and F.T. Lee, First-ply failure strength of laminated composite pressure Vessels. Journal of Composite structure. Vol: 38, No. 1-4, pp.65-70, (1997).

DOI: 10.1016/s0263-8223(97)00042-1

[8] R.R. Chang: Experimental and Theoretical Analysis of First-Ply Failure of Laminated Composite Pressure Vessel. Journal of Composite Structure. Vol: 49: pp.237-243, (2000).

DOI: 10.1016/s0263-8223(99)00133-6

[9] C.T.F. Roaa, Bak Hock Huat, Tay Boon Chei, Chai Min Chong and M.D.A. Mackney: Buckling of GRP Hemi-Ellipsoidal Dome Shells under External Hydrostatic Pressure. Ocean Engineering. Vol: 30: pp.691-705, (2003).

DOI: 10.1016/s0029-8018(02)00039-2

[10] Cho-Chung Liang, Hung-Wen Chen and Cheng-Huan Wang: Optimum Design of Dome Contour for Filament-Wound Composite Pressure Vessels Based on a Shape Factor. Journal of Composite Structures. Vol: 58, pp.469-482, (2002).

DOI: 10.1016/s0263-8223(02)00136-8
