Virtual Prototype Modeling and Dynamical Simulation of Swing Movable Teeth Reducer

Abstract:

Swing movable teeth reducer is a new type of small teeth difference planetary gear reducer, which is used to transmit the rotary motion and power between two shafts with same axis. It is important to carry on the systematic design and performance simulation of the reducer and seek the optimization design of the products by the virtual prototyping. Based on the study of the principles and characteristics of the swing movable teeth transmission, this study established the virtual prototype and achieved the dynamical simulation of the reducer by CAD/CAE software. The rotate speed and force analysis proved the feasibility of the model.

• Periodical: Advanced Materials Research (Volumes 466-467)
• Pages: 1300-1304
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.466-467.1300
• Online since: February 2012
• Authors: Yan Fang Wang, Lu Ning Liu, Bo Yang
• Keywords: Dynamical Simulation, Swing Movable Teeth Reducer, Virtual Prototype

References

[1] Jifang Qu: movable transmission theory, Mechanical Industry Press(1993).

[2] Guoleng Xiong, Bohu Li and Xvdong Chai: Virtual prototype technology, Journal of System Simulation, vol. 13(2001), pp.114-117.

[3] Hezhong Cheng: The research on transmission theory, manufacture and check of swing movable teeth reducer, The master degree theses of Sichuan University(2002).

[4] Jiancheng Zhang, Zhongwen Jia and Minjun Yao: Solid Edge synchronous modeling technology started quickly, Tsinghua University Press(2009).

[5] Jianrong Zheng, ADAMS—Virtual prototype technology introduction and improve, Mechanical Industry Press(2002).
